Запчасти Komatsu S6D125-1AF ТОПЛ. НАСОС (НАСОС) (/) (ВНУТР. ЧАСТИ)(№97-) ДВИГАТЕЛЬ

|1

6151-71-1190

INJECTION PUMP A.

SN: 51976-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3A3 TO A4010-G3A3.

-1шт.

|1

ND190100-0020

BODY ASS'Y

SN: 51976-UP

1шт.

|$$4

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B3A3 AND A4010-C3A3.

-1шт.

1

ND090110-4460

HOUSING

SN: 51976-UP

1шт.

2

ND949043-0010

STUD

SN: 51976-UP

3шт.

3

ND949140-3940

O-RING

SN: 51976-UP

1шт.

4

ND090191-1090

CAMSHAFT

SN: 51976-UP

1шт.

5

ND949101-0140

BEARING,ROLLER

SN: 51976-UP

1шт.

6

ND090193-0050

RING,ADJUST

SN: 51976-UP

1шт.

7

ND090194-0410

PLATE¤ 0.03MM

SN: 51976-UP

-2шт.

|7

ND090194-0070

PLATE¤ 0.1MM

SN: 51976-UP

-2шт.

|7

ND090194-0340

PLATE¤ 0.12MM

SN: 51976-UP

-2шт.

|7

ND090194-0350

PLATE¤ 0.14MM

SN: 51976-UP

-2шт.

|7

ND090194-0080

PLATE¤ 0.15MM

SN: 51976-UP

-2шт.

|7

ND090194-0360

PLATE¤ 0.18MM

SN: 51976-UP

-2шт.

|7

ND090194-0090

PLATE¤ 0.3MM

SN: 51976-UP

-2шт.

|7

ND090194-0100

PLATE¤ 0.5MM

SN: 51976-UP

-2шт.

8

ND949150-2820

SEAL,OIL

SN: 51976-UP

1шт.

9

ND090201-0430

COVER,BEARING

SN: 51976-UP

1шт.

10

ND91518-06161

BOLT

SN: 51976-UP

4шт.

11

ND090433-0020

RETAINER,BEARING

SN: 51976-UP

1шт.

12

ND090361-0180

BEARING,CENTER

SN: 51976-UP

1шт.

13

ND90015-06181

SCREW

SN: 51976-UP

2шт.

14

ND090248-0010

WASHER

SN: 51976-UP

2шт.

15

ND090317-0140

PLUG

SN: 51976-UP

1шт.

16

ND090193-0060

RING,ADJUST

SN: 51976-UP

1шт.

17

ND090222-0070

WASHER

SN: 51976-UP

4шт.

18

ND949180-0310

SCREW

SN: 51976-UP

2шт.

19

ND949140-0380

O-RING

SN: 51976-UP

1шт.

20

ND90160-06051

NUT

SN: 51976-UP

3шт.

21

ND90258-06001

WASHER,SPRING

SN: 51976-UP

3шт.

22

ND949101-0130

BEARING,ROLLER

SN: 51976-UP

1шт.

23

ND090194-0300

PLATE¤ 0.1MM

SN: 51976-UP

-2шт.

|23

ND090194-0370

PLATE¤ 0.12MM

SN: 51976-UP

-2шт.

|23

ND090194-0380

PLATE¤ 0.14MM

SN: 51976-UP

-2шт.

|23

ND090194-0310

PLATE¤ 0.16MM

SN: 51976-UP

-2шт.

|23

ND090194-0390

PLATE¤ 0.18MM

SN: 51976-UP

-2шт.

|23

ND090194-0320

PLATE¤ 0.3MM

SN: 51976-UP

-2шт.

|23

ND090194-0330

PLATE¤ 0.5MM

SN: 51976-UP

-2шт.

24

ND949047-0620

BOLT

SN: 51976-UP

2шт.

25

ND090118-0490

NEEDLE,TIMING

SN: 51976-UP

1шт.

26

ND949018-0350

WASHER

SN: 51976-UP

1шт.

27

ND090012-0140

NUT

SN: 51976-UP

1шт.

28

ND949014-0070

WASHER

SN: 51976-UP

1шт.

29

ND90458-05750

KEY

SN: 51976-UP

1шт.

30

ND090222-0070

WASHER

SN: 51976-UP

2шт.

31

ND090310-0080

VALVE ASS'Y,OVER FLOW

SN: 51976-UP

1шт.
