Артикул
Название
Примечание
Количество
|1
6151-72-1191
INJECTION PUMP A.
SN: 85967-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 61582-85966
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B3J4 T0 A4010-G3J4.
-1шт.
|1
ND190800-4670
GOVERNOR ASS'Y
SN: 61582-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3J4 AND A4010-E3J4.
-1шт.
1
ND090810-0540
HOUSING
SN: 61582-UP
1шт.
2
ND090878-0260
PLATE
SN: 61582-UP
1шт.
3
ND091024-0130
SCREW,ADJUST
SN: 61582-UP
1шт.
4
ND090901-0150
LEVER ASS'Y,TENSION
SN: 61582-UP
1шт.
5
ND090930-0280
LEVER ASS'Y,CONTROL
SN: 61582-UP
1шт.
6
ND090894-0010
E-RING
SN: 61582-UP
1шт.
7
ND948053-0051
NUT
SN: 61582-UP
1шт.
8
ND091046-0010
SLIDER,SUPPORT
SN: 61582-UP
1шт.
9
ND090970-0350
SHACKLE ASS'Y
SN: 61582-UP
1шт.
10
ND949130-0050
KEY
SN: 61582-UP
1шт.
11
ND090840-0520
FLYWEIGHT ASS'Y
SN: 61582-UP
1шт.
12
ND949015-0500
WASHER¤ 2.5MM,SPRING
SN: 61582-UP
1шт.
15
ND090868-0040
PLATE,THRUST
SN: 61582-UP
1шт.
16
ND90567-30000
RING,SNAP
SN: 61582-UP
1шт.
17
ND949013-4090
WASHER¤ 0.1MM
SN: 61582-UP
-2шт.
|17
ND949013-4060
WASHER¤ 0.2MM
SN: 61582-UP
-2шт.
|17
ND949013-4070
WASHER¤ 0.3MM
SN: 61582-UP
-2шт.
|17
ND949013-4080
WASHER¤ 0.4MM
SN: 61582-UP
-2шт.
|17
ND949013-4100
WASHER¤ 1.0MM
SN: 61582-UP
-2шт.
18
ND090992-0310
SPRING,CONTROL
SN: 61582-UP
1шт.
19
ND090993-0280
SPRING,START
SN: 61582-UP
1шт.
|20
ND090910-0630
ADAPTER ASS'Y
SN: 61582-UP
1шт.
20
ND090911-0010
SCREW
SN: 61582-UP
1шт.
21
ND090919-0010
ADAPTER
SN: 61582-UP
1шт.
22
ND090918-1150
SPRING,GOVERNOR
SN: 61582-UP
1шт.
23
ND090921-0010
WASHER,GOVERNOR
SN: 61582-UP
1шт.
24
ND090894-0010
E-RING
SN: 61582-UP
1шт.
25
ND949013-3880
WASHER¤ 0.1MM
SN: 61582-UP
-2шт.
|25
ND949013-4040
WASHER¤ 0.2MM
SN: 61582-UP
-2шт.
|25
ND949013-4020
WASHER¤ 0.25MM
SN: 61582-UP
-2шт.
|25
ND949013-4030
WASHER¤ 0.5MM
SN: 61582-UP
-2шт.
|25
ND949013-7880
WASHER¤ 1.0MM
SN: 61582-UP
-2шт.
26
ND090923-0011
NUT,LOCK
SN: 61582-UP
1шт.
27
ND090224-0140
PLUG
SN: 61582-UP
1шт.
30
ND090245-0230
SCREW
SN: 61582-UP
1шт.
33
ND949047-6880
BOLT
SN: 61582-UP
2шт.
34
ND949047-6910
BOLT
SN: 61582-UP
1шт.
35
ND949047-6900
BOLT
SN: 61582-UP
1шт.
36
ND949047-6890
BOLT
SN: 61582-UP
4шт.
|1
6151-72-1191
INJECTION PUMP A.
SN: 85967-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 61582-85966
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.A4010-B3J4 T0 A4010-G3J4.
-1шт.
|1
ND190800-4670
GOVERNOR ASS'Y
SN: 61582-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-D3J4 AND A4010-E3J4.
-1шт.
1
ND090810-0540
HOUSING
SN: 61582-UP
1шт.
2
ND090878-0260
PLATE
SN: 61582-UP
1шт.
3
ND091024-0130
SCREW,ADJUST
SN: 61582-UP
1шт.
4
ND090901-0150
LEVER ASS'Y,TENSION
SN: 61582-UP
1шт.
5
ND090930-0280
LEVER ASS'Y,CONTROL
SN: 61582-UP
1шт.
6
ND090894-0010
E-RING
SN: 61582-UP
1шт.
7
ND948053-0051
NUT
SN: 61582-UP
1шт.
8
ND091046-0010
SLIDER,SUPPORT
SN: 61582-UP
1шт.
9
ND090970-0350
SHACKLE ASS'Y
SN: 61582-UP
1шт.
10
ND949130-0050
KEY
SN: 61582-UP
1шт.
11
ND090840-0520
FLYWEIGHT ASS'Y
SN: 61582-UP
1шт.
12
ND949015-0500
WASHER¤ 2.5MM,SPRING
SN: 61582-UP
1шт.
15
ND090868-0040
PLATE,THRUST
SN: 61582-UP
1шт.
16
ND90567-30000
RING,SNAP
SN: 61582-UP
1шт.
17
ND949013-4090
WASHER¤ 0.1MM
SN: 61582-UP
-2шт.
|17
ND949013-4060
WASHER¤ 0.2MM
SN: 61582-UP
-2шт.
|17
ND949013-4070
WASHER¤ 0.3MM
SN: 61582-UP
-2шт.
|17
ND949013-4080
WASHER¤ 0.4MM
SN: 61582-UP
-2шт.
|17
ND949013-4100
WASHER¤ 1.0MM
SN: 61582-UP
-2шт.
18
ND090992-0310
SPRING,CONTROL
SN: 61582-UP
1шт.
19
ND090993-0280
SPRING,START
SN: 61582-UP
1шт.
|20
ND090910-0630
ADAPTER ASS'Y
SN: 61582-UP
1шт.
20
ND090911-0010
SCREW
SN: 61582-UP
1шт.
21
ND090919-0010
ADAPTER
SN: 61582-UP
1шт.
22
ND090918-1150
SPRING,GOVERNOR
SN: 61582-UP
1шт.
23
ND090921-0010
WASHER,GOVERNOR
SN: 61582-UP
1шт.
24
ND090894-0010
E-RING
SN: 61582-UP
1шт.
25
ND949013-3880
WASHER¤ 0.1MM
SN: 61582-UP
-2шт.
|25
ND949013-4040
WASHER¤ 0.2MM
SN: 61582-UP
-2шт.
|25
ND949013-4020
WASHER¤ 0.25MM
SN: 61582-UP
-2шт.
|25
ND949013-4030
WASHER¤ 0.5MM
SN: 61582-UP
-2шт.
|25
ND949013-7880
WASHER¤ 1.0MM
SN: 61582-UP
-2шт.
26
ND090923-0011
NUT,LOCK
SN: 61582-UP
1шт.
27
ND090224-0140
PLUG
SN: 61582-UP
1шт.
30
ND090245-0230
SCREW
SN: 61582-UP
1шт.
33
ND949047-6880
BOLT
SN: 61582-UP
2шт.
34
ND949047-6910
BOLT
SN: 61582-UP
1шт.
35
ND949047-6900
BOLT
SN: 61582-UP
1шт.
36
ND949047-6890
BOLT
SN: 61582-UP
4шт.
Выбрано товаров: 100
