Запчасти Komatsu D60P-12-E МАРКИРОВКА (ЯПОН.) (DP)(№-) МАРКИРОВКА

1

09651-A0640

PLATE¤ SAFETY,OPERATION AND MAINTENANCE

SN: 62774-UP

1шт.

2

14X-98-11190

PLATE,PRESSURE TEST (C AND B)

SN: 60884-UP

1шт.

3

14X-98-11220

PLATE¤ OPERATING,TRANSMISSION LEVER

SN: 60884-UP

1шт.

4

14X-98-21450

PLATE,DATA

SN: 65001-UP

1шт.

5

09690-P1000

PLATE¤ MARK,KOMATSU¤ REAR

SN: 65001-UP

1шт.

6

09690-P0560

PLATE¤ MARK,KOMATSU

SN: 65001-UP

3шт.

7

09690-M0063

PLATE¤ MARK,KOMATSU

SN: 65001-UP

1шт.

8

09602-10001

PLATE¤ NAME

SN: 65579-UP

1шт.

|8

09602-10000

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 65001-65578

1шт.

9

04418-13060

SCREW

SN: 60884-UP

4шт.

10

14X-98-23150

PLATE¤ MARK,D60P¤ L.H.

SN: 65001-UP

1шт.

11

14X-98-23250

PLATE¤ MARK,D60P¤ R.H.

SN: 65001-UP

1шт.

12

14X-98-23160

PLATE¤ MARK

SN: 65001-UP

1шт.

13

09657-A0880

PLATE¤ SAFETY,TRACK ADJUSTMENT

SN: 62774-UP

2шт.

14

14X-98-22711

CHART¤ OIL

SN: 65001-UP

1шт.

15

14X-98-11170

PLATE¤ OPERATING,LOCK

SN: 60884-UP

2шт.

16

09963-00101

TAG,DO NOT OPERATE

SN: 65001-UP

1шт.

17

134-98-31370

PLATE¤ CAUTION,HANDLING POSTURE

SN: 61534-UP

1шт.

18

09802-10100

PLATE¤ SAFETY,BEFORE DRIVING

SN: 62774-UP

1шт.

19

09653-A0480

PLATE¤ SAFETY,HOT OIL/WATER

SN: 62774-UP

2шт.

20

09654-B0640

PLATE¤ SAFETY,LEAVING SEAT

SN: 62774-UP

1шт.

21

09667-A0480

PLATE¤ SAFETY,REVOLUTION

SN: 62774-UP

2шт.

22

09806-B1200

PLATE¤ SAFETY,KEEP A SAFE DISTANCE

SN: 62774-UP

2шт.

23

09808-A0880

PLATE¤ SAFETY,BATTERY CABLE

SN: 62774-UP

1шт.

24

0

PLATE,EXHAUST GAS

SN: 65001-UP

1шт.

24A

09669-0000E

PLATE¤ CAUTION,FUEL

SN: 65486-UP

1шт.

25

14X-98-11240

PLATE¤ OPERATING,STEERING LEVER (C AND B)

SN: 60884-UP

1шт.

26

14X-98-11250

PLATE¤ OPERATING,WORK EQUIP.LEVER (TILT DOZER)

SN: 60884-UP

1шт.

|26

14X-98-11270

PLATE¤ OPERATING,WORK EQUIP.LEVER (PITCH DOZER)

SN: 60884-UP

1шт.
