Запчасти Komatsu D60P-12-E КАБИНА (ОСВЕЩЕНИЕ И ЭЛЕКТРОПРОВОДКА) (DP) КАБИНА ОПЕРАТОРА И СИСТЕМА УПРАВЛЕНИЯ

|1

14X-911-0810

CAB ASS'Y,(AM RADIO)

SN: 60884-UP

1шт.

|1

14X-911-0820

CAB ASS'Y,(AM/FM CASSETTE STEREO)

SN: 60884-UP

1шт.

|1

14X-911-0830

CAB ASS'Y,(AM RADIO¤ F.R. WORK LAMP)

SN: 60884-UP

1шт.

|1

14X-911-0840

CAB ASS'Y,(AM/FM CST.ST.¤ F.R.WORK LAMP)

SN: 60884-UP

1шт.

|1

14X-911-0850

CAB ASS'Y,(AM RADIO¤ FRONT WORK LAMP)

SN: 60884-UP

1шт.

|1

14X-911-0860

CAB ASS'Y,(AM/FM CT.ST¤ FRONT WORK LAMP)

SN: 60884-UP

1шт.

|1

14X-911-0870

CAB ASS'Y,(AM RADIO¤ REAR WORK LAMP)

SN: 60884-UP

1шт.

|1

14X-911-0880

CAB ASS'Y,(AM/FM CT.ST¤ REAR WORK LAMP)

SN: 60884-UP

1шт.

|1

14X-911-0890

CAB ASS'Y,(RADIO LESS)

SN: 60884-UP

1шт.

|1

14X-911-0900

CAB ASS'Y,(RADIO LESS¤ F.R. WORK LAMP)

SN: 60884-UP

1шт.

|1

14X-911-0910

CAB ASS'Y,(RADIO LESS¤ FRONT WORK LAMP)

SN: 60884-UP

1шт.

|1

14X-911-0920

CAB ASS'Y,(RADIO LESS¤ REAR WORK LAMP)

SN: 60884-UP

1шт.

|$$13

THESE ASSEMBLY CONSIST OF SOME FIGS. BE CAREFUL WHEN ORDERING THE PARTS.

-1шт.

1

14X-911-4251

BRACKET

SN: 60884-UP

1шт.

2

01435-01020

BOLT

SN: 60884-UP

3шт.

3

14X-911-4121

PANEL

SN: 60884-UP

1шт.

4

01023-20620

SCREW

SN: 60884-UP

5шт.

5

14X-911-4141

BRACKET

SN: 60884-UP

1шт.

6

01220-70516

SCREW

SN: 60884-UP

4шт.

7

08141-02400

LAMP

SN: 60884-UP

1шт.

|7

08116-02410

BULB¤ 10W

SN: 60884-UP

1шт.

8

01023-10420

SCREW

SN: 60884-UP

2шт.

9

14X-911-4511

WIRING HARNESS

SN: 60884-UP

1шт.

10

205-06-71480

FUSE BOX

SN: 60884-UP

1шт.

11

283-06-16190

FUSE¤ 10A

SN: 60884-UP

7шт.

12

22W-06-13160

FUSE¤ 20A

SN: 60884-UP

2шт.

13

14X-911-4541

BOOT

SN: 60884-UP

1шт.

14

14X-911-4551

CLIP

SN: 60884-UP

15шт.

15

14X-911-4521

WIRING HARNESS

SN: 60884-UP

2шт.

16

20T-06-71410

SWITCH

SN: 60884-UP

4шт.

17

14X-911-4280

COVER

SN: 60884-UP

2шт.

18

09415-01008

CAP

SN: 60884-UP

2шт.
