Запчасти Komatsu D58P-1C МАРКИРОВКА (ПОРТУГАЛ.) (REGULATION OF ЕС DYNAMIC NOISE)(№88-) МАРКИРОВКА

1

09690-C0280

PLATE, MARK,HEAD

SN: 81381-UP

1шт.

2

09667-02000

PLATE, SAFETY,ENGINE COVER

SN: 81381-UP

2шт.

3

134-54-35340

PLATE, MARK,STRIPE L.H.

SN: 81381-UP

1шт.

3

134-54-35330

PLATE, MARK,STRIPE R.H.

SN: 81381-UP

1шт.

4

134-98-31331

CHART,OIL

SN: 81381-UP

1шт.

5

13G-54-55240

PLATE, MARK,D58P

SN: 81381-UP

2шт.

6

134-54-35132

PLATE, MARK,STRIPE

SN: 81381-UP

2шт.

7

14X-98-11750

PLATE, SAFETY,TRACK SHOE ADJUSTING

SN: 81381-UP

2шт.

8

09652-21101

PLATE, CAUTION,FUEL TANK WATER DRAIN

SN: 81381-UP

1шт.

9

09656-21080

PLATE, INSTRUCTION,FUEL TANK STRAINER

SN: 81381-UP

1шт.

10

09690-C0400

PLATE, MARK,KOMATSU

SN: 81381-UP

1шт.

11

134-54-35351

PLATE, MARK,WHITE BELT

SN: 81381-UP

3шт.

12

09650-21101

PLATE, INSTRUCTION,RADIATOR WATER LEVEL

SN: 81381-UP

1шт.

13

120-54-32451

SHEET,ANTISKID

SN: 81381-UP

2шт.

14

09670-0000B

PLATE, OPERATING,BLADE CONTROL LEVER

SN: 81381-UP

1шт.

15

09670-0000E

PLATE, OPERATING,BLADE CONTROL LEVER

SN: 81381-UP

1шт.

16

14X-98-11730

PLATE, SAFETY,RADIATOR CAP

SN: 81381-UP

1шт.

17

144-54-25270

PLATE, OPERATING,TRANSMISSION CONTROL

SN: 81381-UP

1шт.

17

04418-13060

SCREW

SN: 81381-UP

6шт.

18

09679-02002

PLATE, OPERATING,HORN SWITCH

SN: 81381-UP

1шт.

19

124-98-26320

PLATE, SAFETY,AFTER OPERATING

SN: 81381-UP

1шт.

20

09651-02001

PLATE, SAFETY,BEFORE OPERATING

SN: 81381-UP

1шт.

21

362-54-17320

PLATE, OPERATING,FUEL CONTROL

SN: 81381-UP

1шт.

22

08670-12001

INDICATOR,DUST

SN: 81381-UP

1шт.

23

09683-0000E

PLATE, OPERATING,STARTING SWITCH

SN: 81414-UP

1шт.

23

09683-21060

PLATE, OPERATING,STARTING SWITCH

SN: 81381-81413

1шт.

24

09602-00000

PLATE, NAME,(LIMITED SUPPLY)

SN: 81381-UP

1шт.

24

04418-13060

SCREW

SN: 81381-UP

4шт.

25

14X-98-11720

PLATE, SAFETY,HYDRAULIC TANK

SN: 81381-UP

1шт.

26

09655-21120

PLATE, INSTRUCTION,OIL FILTER

SN: 81381-UP

1шт.

27

09685-00005

PLATE, OPERATING,BLADE CONTROL LEVER LOCK

SN: 81381-UP

1шт.

28

09685-00010

PLATE, OPERATING,PARKING BRAKE LOCK

SN: 81381-UP

1шт.

29

09685-00002

PLATE, OPERATING,T/M CONTROL LEVER LOCK

SN: 81381-UP

1шт.

30

124-98-51240

PLATE, SAFETY,KEEP A SAFE DISTANCE

SN: 81414-UP

2шт.

30

17A-98-11730

PLATE, CAUTION,KEEP A SAFE DISTANCE

SN: 81381-81413

2шт.

31

09696-00108

PLATE,SURROUNDING NOISE

SN: 81381-UP

1шт.

32

09963-02000

TAG,DO NOT OPERATE

SN: 81381-UP

1шт.

33

09960-01001

PLATE, MARK,SLINGING POSITION

SN: 81381-UP

4шт.
