Артикул
Название
Примечание
Количество
|1
6166-71-1531
INJECTION PUMP ASS'Y,L.H.
SN: 10139-UP
1шт.
|1
0
INJECTION PUMP ASS'Y,L.H.
SN: 10097-10138
1шт.
|$$3
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B8A1¤C8A1¤F8A1¤G8A1 AND A4010-H8A1.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105447-1970
GOVERNOR ASS'Y
SN: 10139-UP
1шт.
|1
DK105447-1510
GOVERNOR ASS'Y
SN: 10097-10138
1шт.
|$$7
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-F8A1 AND A4010-G8A1.
-1шт.
1
DK154520-8020
COVER ASS'Y,GOVERNOR
SN: 10097-UP
1шт.
2
DK154031-3000
SCREW
SN: 10097-UP
1шт.
3
DK139206-0600
NUT
SN: 10139-UP
1шт.
|3
DK013020-6040
NUT
SN: 10097-10138
1шт.
4
DK154036-0300
PLUG
SN: 10097-UP
2шт.
5
DK020106-5040
BOLT
SN: 10097-UP
4шт.
6
DK020106-2840
BOLT
SN: 10097-UP
3шт.
9
DK154063-0900
COVER
SN: 10097-UP
1шт.
10
DK029020-6210
BOLT
SN: 10097-UP
2шт.
11
DK020006-1640
BOLT
SN: 10097-UP
2шт.
14
DK154158-0620
CAPSULE,SPRING
SN: 10097-UP
1шт.
15
DK029201-2290
NUT
SN: 10097-UP
1шт.
18
DK154200-7520
LEVER,SWIVEL
SN: 10097-UP
1шт.
22
DK016010-1640
RING,SNAP
SN: 10097-UP
2шт.
28
DK154395-4820
LEVER
SN: 10097-UP
1шт.
34
DK154372-7200
NUT,LOCK
SN: 10097-UP
1шт.
35
DK026510-1440
GASKET
SN: 10097-UP
1шт.
36
DK154401-4500
BOLT
SN: 10097-UP
1шт.
37
DK154402-8100
SPRING
SN: 10097-UP
1шт.
38
DK154404-5000
COVER
SN: 10097-UP
1шт.
40
DK154034-1900
SCREW
SN: 10097-UP
1шт.
|44
DK029312-0210
SHIM¤ 0.2MM
SN: 10097-UP
-2шт.
52
DK131002-3800
ADAPTER
SN: 10097-UP
1шт.
54
DK154373-1800
EYE
SN: 10097-UP
1шт.
55
DK154373-1700
BOLT,EYE
SN: 10097-UP
1шт.
|1
6166-71-1531
INJECTION PUMP ASS'Y,L.H.
SN: 10139-UP
1шт.
|1
0
INJECTION PUMP ASS'Y,L.H.
SN: 10097-10138
1шт.
|$$3
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-B8A1¤C8A1¤F8A1¤G8A1 AND A4010-H8A1.
-1шт.
|$$4
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105447-1970
GOVERNOR ASS'Y
SN: 10139-UP
1шт.
|1
DK105447-1510
GOVERNOR ASS'Y
SN: 10097-10138
1шт.
|$$7
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A4010-F8A1 AND A4010-G8A1.
-1шт.
1
DK154520-8020
COVER ASS'Y,GOVERNOR
SN: 10097-UP
1шт.
2
DK154031-3000
SCREW
SN: 10097-UP
1шт.
3
DK139206-0600
NUT
SN: 10139-UP
1шт.
|3
DK013020-6040
NUT
SN: 10097-10138
1шт.
4
DK154036-0300
PLUG
SN: 10097-UP
2шт.
5
DK020106-5040
BOLT
SN: 10097-UP
4шт.
6
DK020106-2840
BOLT
SN: 10097-UP
3шт.
9
DK154063-0900
COVER
SN: 10097-UP
1шт.
10
DK029020-6210
BOLT
SN: 10097-UP
2шт.
11
DK020006-1640
BOLT
SN: 10097-UP
2шт.
14
DK154158-0620
CAPSULE,SPRING
SN: 10097-UP
1шт.
15
DK029201-2290
NUT
SN: 10097-UP
1шт.
18
DK154200-7520
LEVER,SWIVEL
SN: 10097-UP
1шт.
22
DK016010-1640
RING,SNAP
SN: 10097-UP
2шт.
28
DK154395-4820
LEVER
SN: 10097-UP
1шт.
34
DK154372-7200
NUT,LOCK
SN: 10097-UP
1шт.
35
DK026510-1440
GASKET
SN: 10097-UP
1шт.
36
DK154401-4500
BOLT
SN: 10097-UP
1шт.
37
DK154402-8100
SPRING
SN: 10097-UP
1шт.
38
DK154404-5000
COVER
SN: 10097-UP
1шт.
40
DK154034-1900
SCREW
SN: 10097-UP
1шт.
|44
DK029312-0210
SHIM¤ 0.2MM
SN: 10097-UP
-2шт.
52
DK131002-3800
ADAPTER
SN: 10097-UP
1шт.
54
DK154373-1800
EYE
SN: 10097-UP
1шт.
55
DK154373-1700
BOLT,EYE
SN: 10097-UP
1шт.
Выбрано товаров: 134
