|1
6166-71-1550
INJECTION PUMP ASS'Y,R.H.
SN: 10024-10096
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401A-D8A1¤E8A1 AND A401A- J8A1.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105235-1890
FEED PUMP ASS'Y
SN: 10024-10096
1шт.
1
DK152002-2320
HOUSING
SN: 10024-10096
1шт.
2
DK152100-1120
PISTON
SN: 10024-10096
1шт.
3
DK152104-0400
SPRING,PISTON
SN: 10024-10096
1шт.
4
DK152105-1500
PLUG
SN: 10024-10096
1шт.
5
DK152111-4420
TAPPET ASS'Y
SN: 10024-10096
1шт.
6
DK152112-0800
ROLLER
SN: 10024-10096
1шт.
7
DK152113-1300
PIN
SN: 10024-10096
1шт.
8
DK152114-1600
GUIDE
SN: 10024-10096
2шт.
9
DK152115-0500
VALVE
SN: 10024-10096
4шт.
10
DK152116-0200
SPRING
SN: 10024-10096
4шт.
11
DK152117-0400
PLUG
SN: 10024-10096
2шт.
12
DK152118-1000
ADAPTER
SN: 10024-10096
1шт.
13
DK029631-6060
O-RING
SN: 10024-10096
1шт.
14
DK152121-0200
RING,SNAP
SN: 10024-10096
1шт.
15
DK152200-5320
PUMP,PRIMING
SN: 10024-10096
1шт.
16
DK152300-7320
BOLT,EYE
SN: 10024-10096
1шт.
17
DK134045-0100
PLUG
SN: 10024-10096
1шт.
18
DK029341-4130
GASKET
SN: 10024-10096
2шт.
19
DK132400-0200
ADAPTER
SN: 10024-10096
1шт.
20
DK152320-0100
COVER
SN: 10024-10096
1шт.
21
DK029731-4680
BOLT,EYE
SN: 10024-10096
1шт.
22
DK029341-4130
GASKET
SN: 10024-10096
2шт.
|1
6166-71-1550
INJECTION PUMP ASS'Y,R.H.
SN: 10024-10096
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.A401A-D8A1¤E8A1 AND A401A- J8A1.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105235-1890
FEED PUMP ASS'Y
SN: 10024-10096
1шт.
1
DK152002-2320
HOUSING
SN: 10024-10096
1шт.
2
DK152100-1120
PISTON
SN: 10024-10096
1шт.
3
DK152104-0400
SPRING,PISTON
SN: 10024-10096
1шт.
4
DK152105-1500
PLUG
SN: 10024-10096
1шт.
5
DK152111-4420
TAPPET ASS'Y
SN: 10024-10096
1шт.
6
DK152112-0800
ROLLER
SN: 10024-10096
1шт.
7
DK152113-1300
PIN
SN: 10024-10096
1шт.
8
DK152114-1600
GUIDE
SN: 10024-10096
2шт.
9
DK152115-0500
VALVE
SN: 10024-10096
4шт.
10
DK152116-0200
SPRING
SN: 10024-10096
4шт.
11
DK152117-0400
PLUG
SN: 10024-10096
2шт.
12
DK152118-1000
ADAPTER
SN: 10024-10096
1шт.
13
DK029631-6060
O-RING
SN: 10024-10096
1шт.
14
DK152121-0200
RING,SNAP
SN: 10024-10096
1шт.
15
DK152200-5320
PUMP,PRIMING
SN: 10024-10096
1шт.
16
DK152300-7320
BOLT,EYE
SN: 10024-10096
1шт.
17
DK134045-0100
PLUG
SN: 10024-10096
1шт.
18
DK029341-4130
GASKET
SN: 10024-10096
2шт.
19
DK132400-0200
ADAPTER
SN: 10024-10096
1шт.
20
DK152320-0100
COVER
SN: 10024-10096
1шт.
21
DK029731-4680
BOLT,EYE
SN: 10024-10096
1шт.
22
DK029341-4130
GASKET
SN: 10024-10096
2шт.
