Запчасти Komatsu 6D125-1D ТОПЛ. НАСОС (СОЕДИНЕНИЕ)(№79-) ТОПЛИВН. СИСТЕМА

|1

6150-71-1220

INJECTION PUMP A.

SN: 11479-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453A TO 0482A.

-1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND092500-0770

COUPLING ASS'Y

SN: 11479-UP

1шт.

1

ND092415-0610

FLANGE

SN: 11479-UP

1шт.

2

ND092437-0350

COUPLING,CROSS

SN: 11479-UP

1шт.

3

ND092460-0051

PLATE SUB ASS'Y

SN: 11479-UP

2шт.

4

ND949040-6640

BOLT

SN: 11479-UP

2шт.

5

ND949040-6361

BOLT

SN: 11479-UP

6шт.

6

ND092433-0150

BOLT

SN: 11479-UP

1шт.

7

ND092431-0130

NUT

SN: 11479-UP

2шт.

8

ND092551-0530

BLOCK,COUPLING

SN: 11479-UP

2шт.
