Запчасти Komatsu 6D125-1D ТОПЛИВН. ФОРСУНКА И СЛИВНАЯ ТРУБКА ТОПЛИВН. СИСТЕМА

|1

6150-11-3101

NOZZLE HOLDER ASS'Y

SN: 10001-UP

6шт.

|1

6150-11-3111

HOLDER ASS'Y

SN: 10001-UP

1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

ND093111-2710

BODY

SN: 10001-UP

1шт.

2

ND093121-0320

PIN,PRESSURE

SN: 10001-UP

1шт.

3

ND093127-0270

SPRING,PRESSURE

SN: 10001-UP

1шт.

4

ND093175-1020

SHIM¤ 0.7MM

SN: 10001-UP

-2шт.

|4

ND093175-1500

SHIM¤ 0.725MM

SN: 10001-UP

-2шт.

|4

ND093175-1030

SHIM¤ 0.75MM

SN: 10001-UP

-2шт.

|4

ND093175-1510

SHIM¤ 0.775MM

SN: 10001-UP

-2шт.

|4

ND093175-1040

SHIM¤ 0.8MM

SN: 10001-UP

-2шт.

|4

ND093175-1520

SHIM¤ 0.825MM

SN: 10001-UP

-2шт.

|4

ND093175-1050

SHIM¤ 0.85MM

SN: 10001-UP

-2шт.

|4

ND093175-1530

SHIM¤ 0.875MM

SN: 10001-UP

-2шт.

|4

ND093175-1060

SHIM¤ 0.9MM

SN: 10001-UP

-2шт.

|4

ND093175-1540

SHIM¤ 0.925MM

SN: 10001-UP

-2шт.

|4

ND093175-1070

SHIM¤ 0.95MM

SN: 10001-UP

-2шт.

|4

ND093175-1550

SHIM¤ 0.975MM

SN: 10001-UP

-2шт.

|4

ND093175-1080

SHIM¤ 1.0MM

SN: 10001-UP

-2шт.

|4

ND093175-1560

SHIM¤ 1.025MM

SN: 10001-UP

-2шт.

|4

ND093175-1090

SHIM¤ 1.05MM

SN: 10001-UP

-2шт.

|4

ND093175-1570

SHIM¤ 1.075MM

SN: 10001-UP

-2шт.

|4

ND093175-1100

SHIM¤ 1.1MM

SN: 10001-UP

-2шт.

|4

ND093175-1580

SHIM¤ 1.125MM

SN: 10001-UP

-2шт.

|4

ND093175-1110

SHIM¤ 1.15MM

SN: 10001-UP

-2шт.

|4

ND093175-1590

SHIM¤ 1.175MM

SN: 10001-UP

-2шт.

|4

ND093175-1120

SHIM¤ 1.2MM

SN: 10001-UP

-2шт.

|4

ND093175-1600

SHIM¤ 1.225MM

SN: 10001-UP

-2шт.

|4

ND093175-1130

SHIM¤ 1.25MM

SN: 10001-UP

-2шт.

|4

ND093175-1610

SHIM¤ 1.275MM

SN: 10001-UP

-2шт.

|4

ND093175-1140

SHIM¤ 1.3MM

SN: 10001-UP

-2шт.

|4

ND093175-1620

SHIM¤ 1.325MM

SN: 10001-UP

-2шт.

|4

ND093175-1150

SHIM¤ 1.35MM

SN: 10001-UP

-2шт.

|4

ND093175-1630

SHIM¤ 1.375MM

SN: 10001-UP

-2шт.

|4

ND093175-1160

SHIM¤ 1.4MM

SN: 10001-UP

-2шт.

|4

ND093175-1640

SHIM¤ 1.425MM

SN: 10001-UP

-2шт.

|4

ND093175-1170

SHIM¤ 1.45MM

SN: 10001-UP

-2шт.

|4

ND093175-1650

SHIM¤ 1.475MM

SN: 10001-UP

-2шт.

|4

ND093175-1180

SHIM¤ 1.5MM

SN: 10001-UP

-2шт.

5

ND093220-0050

PACKING

SN: 10001-UP

1шт.

6

ND093164-1120

NUT,RETAINING

SN: 10001-UP

1шт.

7

ND093151-0390

CONNECTOR,INLET

SN: 10001-UP

1шт.

8

ND093158-0010

GASKET

SN: 10001-UP

1шт.

9

ND093166-0010

SCREW

SN: 10001-UP

1шт.

10

07005-00812

GASKET (K1)

SN: 10001-UP

2шт.

11

6150-11-3120

NOZZLE

SN: 10001-UP

1шт.

12

07000-65065

O-RING (K1)

SN: 10001-UP

6шт.

13

01011-51045

BOLT

SN: 10001-UP

12шт.

14

07005-01012

GASKET (K1)

SN: 10001-UP

12шт.

15

6150-71-5340

TUBE,SPILL

SN: 10064-UP

1шт.

|15

6150-71-5330

TUBE,SPILL

SN: 10001-10063

1шт.

|1

6150-11-3101

NOZZLE HOLDER ASS'Y

SN: 10001-UP

6шт.

|1

6150-11-3111

HOLDER ASS'Y

SN: 10001-UP

1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

ND093111-2710

BODY

SN: 10001-UP

1шт.

2

ND093121-0320

PIN,PRESSURE

SN: 10001-UP

1шт.

3

ND093127-0270

SPRING,PRESSURE

SN: 10001-UP

1шт.

4

ND093175-1020

SHIM¤ 0.7MM

SN: 10001-UP

-2шт.

|4

ND093175-1500

SHIM¤ 0.725MM

SN: 10001-UP

-2шт.

|4

ND093175-1030

SHIM¤ 0.75MM

SN: 10001-UP

-2шт.

|4

ND093175-1510

SHIM¤ 0.775MM

SN: 10001-UP

-2шт.

|4

ND093175-1040

SHIM¤ 0.8MM

SN: 10001-UP

-2шт.

|4

ND093175-1520

SHIM¤ 0.825MM

SN: 10001-UP

-2шт.

|4

ND093175-1050

SHIM¤ 0.85MM

SN: 10001-UP

-2шт.

|4

ND093175-1530

SHIM¤ 0.875MM

SN: 10001-UP

-2шт.

|4

ND093175-1060

SHIM¤ 0.9MM

SN: 10001-UP

-2шт.

|4

ND093175-1540

SHIM¤ 0.925MM

SN: 10001-UP

-2шт.

|4

ND093175-1070

SHIM¤ 0.95MM

SN: 10001-UP

-2шт.

|4

ND093175-1550

SHIM¤ 0.975MM

SN: 10001-UP

-2шт.

|4

ND093175-1080

SHIM¤ 1.0MM

SN: 10001-UP

-2шт.

|4

ND093175-1560

SHIM¤ 1.025MM

SN: 10001-UP

-2шт.

|4

ND093175-1090

SHIM¤ 1.05MM

SN: 10001-UP

-2шт.

|4

ND093175-1570

SHIM¤ 1.075MM

SN: 10001-UP

-2шт.

|4

ND093175-1100

SHIM¤ 1.1MM

SN: 10001-UP

-2шт.

|4

ND093175-1580

SHIM¤ 1.125MM

SN: 10001-UP

-2шт.

|4

ND093175-1110

SHIM¤ 1.15MM

SN: 10001-UP

-2шт.

|4

ND093175-1590

SHIM¤ 1.175MM

SN: 10001-UP

-2шт.

|4

ND093175-1120

SHIM¤ 1.2MM

SN: 10001-UP

-2шт.

|4

ND093175-1600

SHIM¤ 1.225MM

SN: 10001-UP

-2шт.

|4

ND093175-1130

SHIM¤ 1.25MM

SN: 10001-UP

-2шт.

|4

ND093175-1610

SHIM¤ 1.275MM

SN: 10001-UP

-2шт.

|4

ND093175-1140

SHIM¤ 1.3MM

SN: 10001-UP

-2шт.

|4

ND093175-1620

SHIM¤ 1.325MM

SN: 10001-UP

-2шт.

|4

ND093175-1150

SHIM¤ 1.35MM

SN: 10001-UP

-2шт.

|4

ND093175-1630

SHIM¤ 1.375MM

SN: 10001-UP

-2шт.

|4

ND093175-1160

SHIM¤ 1.4MM

SN: 10001-UP

-2шт.

|4

ND093175-1640

SHIM¤ 1.425MM

SN: 10001-UP

-2шт.

|4

ND093175-1170

SHIM¤ 1.45MM

SN: 10001-UP

-2шт.

|4

ND093175-1650

SHIM¤ 1.475MM

SN: 10001-UP

-2шт.

|4

ND093175-1180

SHIM¤ 1.5MM

SN: 10001-UP

-2шт.

5

ND093220-0050

PACKING

SN: 10001-UP

1шт.

6

ND093164-1120

NUT,RETAINING

SN: 10001-UP

1шт.

7

ND093151-0390

CONNECTOR,INLET

SN: 10001-UP

1шт.

8

ND093158-0010

GASKET

SN: 10001-UP

1шт.

9

ND093166-0010

SCREW

SN: 10001-UP

1шт.

10

07005-00812

GASKET (K1)

SN: 10001-UP

2шт.

11

6150-11-3120

NOZZLE

SN: 10001-UP

1шт.

12

07000-65065

O-RING (K1)

SN: 10001-UP

6шт.

13

01011-51045

BOLT

SN: 10001-UP

12шт.

14

07005-01012

GASKET (K1)

SN: 10001-UP

12шт.

15

6150-71-5340

TUBE,SPILL

SN: 10064-UP

1шт.

|15

6150-71-5330

TUBE,SPILL

SN: 10001-10063

1шт.
