Артикул
Название
Примечание
Количество
|1
6150-71-1221
INJECTION PUMP A.
SN: 36147-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 26684-36146
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.
-1шт.
|$$4
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090100-7580
BODY ASS'Y
SN: 26684-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453 AND 0454.
-1шт.
1
ND190110-4110
HOUSING
SN: 26684-UP
1шт.
2
ND949043-0010
STUD
SN: 26684-UP
3шт.
3
ND090191-1180
CAMSHAFT
SN: 26684-UP
1шт.
4
ND090193-0020
RING
SN: 26684-UP
1шт.
5
ND090194-0010
SHIM¤ 0.10MM
SN: 26684-UP
-2шт.
|5
ND090194-0020
SHIM¤ 0.12MM
SN: 26684-UP
-2шт.
|5
ND090194-0030
SHIM¤ 0.14MM
SN: 26684-UP
-2шт.
|5
ND090194-0040
SHIM¤ 0.16MM
SN: 26684-UP
-2шт.
|5
ND090194-0050
SHIM¤ 0.18MM
SN: 26684-UP
-2шт.
|5
ND090194-0110
SHIM¤ 0.3MM
SN: 26684-UP
-2шт.
|5
ND090194-0060
SHIM¤ 0.50MM
SN: 26684-UP
-2шт.
|5
ND090194-0140
SHIM¤ 1.0MM
SN: 26684-UP
-2шт.
|5
ND090194-0150
SHIM¤ 1.5MM
SN: 26684-UP
-2шт.
6
ND090201-0310
COVER
SN: 26684-UP
1шт.
7
ND949140-1550
O-RING
SN: 26684-UP
1шт.
8
ND949150-1620
SEAL,OIL
SN: 26684-UP
1шт.
|9
ND090270-0691
COVER ASS'Y
SN: 26684-UP
1шт.
9
ND090275-0083
COVER
SN: 26684-UP
1шт.
10
ND090272-0220
GASKET
SN: 26684-UP
1шт.
11
ND090243-0030
WASHER
SN: 26684-UP
2шт.
12
ND090276-0030
SCREW
SN: 26684-UP
2шт.
13
ND949047-1360
BOLT
SN: 26684-UP
4шт.
14
ND949101-0120
BEARING
SN: 26684-UP
1шт.
16
ND090310-0080
VALVE ASS'Y,OVER FLOW
SN: 26684-UP
1шт.
17
ND090361-0040
BEARING,CENTER
SN: 26684-UP
1шт.
18
ND91050-05351
SCREW
SN: 26684-UP
2шт.
19
ND949018-1030
WASHER
SN: 26684-UP
2шт.
22
ND090193-0050
RING
SN: 26684-UP
1шт.
23
ND090194-0070
PLATE¤ 0.1MM
SN: 26684-UP
-2шт.
|23
ND090194-0340
PLATE¤ 0.12MM
SN: 26684-UP
-2шт.
|23
ND090194-0350
PLATE¤ 0.14MM
SN: 26684-UP
-2шт.
|23
ND090194-0080
PLATE¤ 0.15MM
SN: 26684-UP
-2шт.
|23
ND090194-0360
PLATE¤ 0.18MM
SN: 26684-UP
-2шт.
|23
ND090194-0090
PLATE¤ 0.3MM
SN: 26684-UP
-2шт.
|23
ND090194-0100
PLATE¤ 0.5MM
SN: 26684-UP
-2шт.
24
ND949101-0071
BEARING
SN: 26684-UP
1шт.
25
ND090012-0180
NUT
SN: 26684-UP
1шт.
26
ND90258-08001
WASHER,SPRING
SN: 26684-UP
1шт.
27
ND949130-0210
KEY
SN: 26684-UP
1шт.
|1
6150-71-1221
INJECTION PUMP A.
SN: 36147-UP
1шт.
|1
0
INJECTION PUMP A.
SN: 26684-36146
1шт.
|$$3
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0453 TO 0482.
-1шт.
|$$4
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090100-7580
BODY ASS'Y
SN: 26684-UP
1шт.
|$$6
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453 AND 0454.
-1шт.
1
ND190110-4110
HOUSING
SN: 26684-UP
1шт.
2
ND949043-0010
STUD
SN: 26684-UP
3шт.
3
ND090191-1180
CAMSHAFT
SN: 26684-UP
1шт.
4
ND090193-0020
RING
SN: 26684-UP
1шт.
5
ND090194-0010
SHIM¤ 0.10MM
SN: 26684-UP
-2шт.
|5
ND090194-0020
SHIM¤ 0.12MM
SN: 26684-UP
-2шт.
|5
ND090194-0030
SHIM¤ 0.14MM
SN: 26684-UP
-2шт.
|5
ND090194-0040
SHIM¤ 0.16MM
SN: 26684-UP
-2шт.
|5
ND090194-0050
SHIM¤ 0.18MM
SN: 26684-UP
-2шт.
|5
ND090194-0110
SHIM¤ 0.3MM
SN: 26684-UP
-2шт.
|5
ND090194-0060
SHIM¤ 0.50MM
SN: 26684-UP
-2шт.
|5
ND090194-0140
SHIM¤ 1.0MM
SN: 26684-UP
-2шт.
|5
ND090194-0150
SHIM¤ 1.5MM
SN: 26684-UP
-2шт.
6
ND090201-0310
COVER
SN: 26684-UP
1шт.
7
ND949140-1550
O-RING
SN: 26684-UP
1шт.
8
ND949150-1620
SEAL,OIL
SN: 26684-UP
1шт.
|9
ND090270-0691
COVER ASS'Y
SN: 26684-UP
1шт.
9
ND090275-0083
COVER
SN: 26684-UP
1шт.
10
ND090272-0220
GASKET
SN: 26684-UP
1шт.
11
ND090243-0030
WASHER
SN: 26684-UP
2шт.
12
ND090276-0030
SCREW
SN: 26684-UP
2шт.
13
ND949047-1360
BOLT
SN: 26684-UP
4шт.
14
ND949101-0120
BEARING
SN: 26684-UP
1шт.
16
ND090310-0080
VALVE ASS'Y,OVER FLOW
SN: 26684-UP
1шт.
17
ND090361-0040
BEARING,CENTER
SN: 26684-UP
1шт.
18
ND91050-05351
SCREW
SN: 26684-UP
2шт.
19
ND949018-1030
WASHER
SN: 26684-UP
2шт.
22
ND090193-0050
RING
SN: 26684-UP
1шт.
23
ND090194-0070
PLATE¤ 0.1MM
SN: 26684-UP
-2шт.
|23
ND090194-0340
PLATE¤ 0.12MM
SN: 26684-UP
-2шт.
|23
ND090194-0350
PLATE¤ 0.14MM
SN: 26684-UP
-2шт.
|23
ND090194-0080
PLATE¤ 0.15MM
SN: 26684-UP
-2шт.
|23
ND090194-0360
PLATE¤ 0.18MM
SN: 26684-UP
-2шт.
|23
ND090194-0090
PLATE¤ 0.3MM
SN: 26684-UP
-2шт.
|23
ND090194-0100
PLATE¤ 0.5MM
SN: 26684-UP
-2шт.
24
ND949101-0071
BEARING
SN: 26684-UP
1шт.
25
ND090012-0180
NUT
SN: 26684-UP
1шт.
26
ND90258-08001
WASHER,SPRING
SN: 26684-UP
1шт.
27
ND949130-0210
KEY
SN: 26684-UP
1шт.
Выбрано товаров: 96
