Запчасти Komatsu 6D125-1C СТАРТЕР (7.KW) (/) ЭЛЕКТРИКА

|1

600-813-3670

STARTING MOTOR ASS'Y,(7.5KW)

SN: 10001-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0662 AND 0663.

-1шт.

|$$3

THE NIKKO DENKI PART NUMBER IS THAT KD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

KD0-23303-0020

PIN,LEVER

SN: 10001-UP

1шт.

2

KD1-0345-08001

WASHER,SEAL

SN: 10001-UP

2шт.

3

KD1-23320-0190

SHIFT LEVER ASS'Y

SN: 10001-UP

1шт.

4

KD1-09279-0090

NUT

SN: 10001-UP

1шт.

5

KD0-47100-3421

MAGNETIC SWITCH A.

SN: 10001-UP

1шт.

6

KD0-47903-0610

SCREW

SN: 10001-UP

1шт.

7

KD1-47120-1660

PLUNGER ASS'Y

SN: 10001-UP

1шт.

8

KD1-47943-0780

BUSHING,INSULATE

SN: 10001-UP

1шт.

9

KD1-47151-0530

CONTACTOR,MOVING

SN: 10001-UP

1шт.

10

KD1-47941-0550

WASHER,INSULATE

SN: 10001-UP

1шт.

11

KD1-47921-1020

WASHER

SN: 10001-UP

2шт.

12

KD1-47927-1030

HOLDER

SN: 10001-UP

1шт.

13

KD1-47914-0090

RING,CLIP

SN: 10001-UP

2шт.

14

KD0-47780-0631

TERMINAL ASS'Y

SN: 10001-UP

1шт.

15

KD1-0345-05001

WASHER,SEAL

SN: 10001-UP

2шт.

16

KD0-09011-2120

SCREW

SN: 10001-UP

2шт.

17

KD7-09210-1000

SEAL ASS'Y,(NOT SHOWN)

SN: 10001-UP

1шт.
