1
134-13-05011
SERVICE KIT,TORQUE CONVERTOR
SN: K1001-UP
1шт.
1
07000-05430
O-RING,HOUSING
SN: K1001-UP
1шт.
1
07000-32135
O-RING,COVER
SN: K1001-UP
1шт.
1
566-13-13310
SEAL,OIL, COUPLING
SN: K1001-UP
1шт.
1
07000-65060
O-RING,COUPLING
SN: K1001-UP
1шт.
1
135-13-31440
LOCK,COUPLING
SN: K1001-UP
1шт.
1
07000-35185
O-RING,COVER
SN: K1001-UP
2шт.
1
07000-62095
O-RING,COVER
SN: K1001-UP
1шт.
1
07000-33032
O-RING,PLUG
SN: K1001-UP
1шт.
1
07000-33022
O-RING,PLUG
SN: K1001-UP
1шт.
1
07000-63025
O-RING,VALVE
SN: K1001-UP
2шт.
1
07000-62014
O-RING,VALVE
SN: K1001-UP
1шт.
2
134-15-05100
SERVICE KIT,TRANSMISSION
SN: 65001-UP
1шт.
2
07000-03035
O-RING,FILLER
SN: 65001-UP
1шт.
2
07000-03028
O-RING,FILLER
SN: 65001-UP
1шт.
2
07002-02434
O-RING,GAUGE
SN: .-UP
2шт.
2
07000-03022
O-RING,GAUGE
SN: 65001-.
2шт.
2
07000-05440
O-RING,TRANSMISSION CASE
SN: 65001-UP
1шт.
2
07002-03634
O-RING,PLUG
SN: 65001-UP
1шт.
2
07000-73050
O-RING,TRANSMISSION CASE
SN: 65001-UP
1шт.
2
07000-73030
O-RING,CASE, MAGNET ASS'Y
SN: 65001-UP
1шт.
2
07000-72055
O-RING,MAGNET
SN: 65001-UP
1шт.
2
07000-72070
O-RING,COVER
SN: 65001-UP
1шт.
2
07000-73022
O-RING,SLEEVE
SN: 65001-UP
6шт.
2
07000-73035
O-RING,TRANSMISSION CASE
SN: 65001-UP
2шт.
2
07000-05410
O-RING,TRANSMISSION CASE
SN: 65001-UP
1шт.
2
134-15-11122
GASKET,PLATE
SN: 65001-UP
1шт.
2
07000-05425
O-RING,PLATE
SN: 65001-UP
1шт.
2
07000-73038
O-RING,PLATE
SN: 65001-UP
1шт.
2
07000-72016
O-RING,PLATE
SN: 65001-UP
1шт.
2
07000-73045
O-RING,PLATE
SN: 65001-UP
1шт.
2
07000-05170
O-RING,CAGE
SN: 65001-UP
2шт.
2
07012-10070
SEAL,OIL, CAGE
SN: 65001-UP
1шт.
2
07000-73030
O-RING,HOUSING
SN: 65001-UP
4шт.
2
144-15-29110
SEAL,OIL, LEVER
SN: 65001-UP
2шт.
2
125-15-11520
LOCK,LEVER
SN: 65001-UP
2шт.
2
07000-72014
O-RING,LEVER
SN: 65001-UP
1шт.
2
135-15-31620
GASKET,TRANSMISSION CASE COVER
SN: 65001-UP
1шт.
2
113-15-11640
GASKET,COVER
SN: 65001-UP
1шт.
3
134-15-05110
SERVICE KIT,TRANSMISSION VALVE
SN: 65001-UP
1шт.
3
07000-73038
O-RING,COVER
SN: 65001-UP
1шт.
3
07000-73025
O-RING,BODY
SN: 65001-UP
5шт.
3
07000-73030
O-RING,BODY
SN: 65001-UP
6шт.
3
135-15-34120
GASKET,LUBRICATION VALVE
SN: .-UP
1шт.
3
0
GASKET,LUBRICATION VALVE
SN: 65001-.
1шт.
3
07000-73025
O-RING,LUBRICATION VALVE
SN: 65001-UP
1шт.
4
130-43-05150
SERVICE KIT,STEERING BRAKE
SN: 65001-UP
1шт.
4
04050-04025
PIN
SN: 65001-UP
2шт.
4
125-33-21390
GASKET,BRACKET
SN: .-UP
2шт.
4
0
GASKET,BRACKET
SN: 65001-.
2шт.
4
130-43-51121
GASKET,STEERING CASE
SN: 65001-UP
1шт.
4
125-43-22330
GASKET,COVER
SN: 65001-UP
2шт.
4
135-43-31160
GASKET,PLATE
SN: 65001-UP
1шт.
4
130-814-5350
GASKET,COVER
SN: 65001-UP
2шт.
4
06122-03004
SEAL,DUST, SHAFT
SN: 65001-UP
4шт.
4
04050-04025
PIN
SN: 65001-UP
4шт.
5
124-40-05010
SERVICE KIT,STEERING VALVE
SN: 65001-UP
1шт.
5
07000-73022
O-RING,HOUSING
SN: 65001-.
1шт.
5
07000-03022
O-RING
SN: .-UP
1шт.
5
07012-00025
SEAL,OIL, SHAFT
SN: 65001-UP
2шт.
5
07000-03028
O-RING,COVER
SN: 65001-UP
2шт.
5
125-40-21150
GASKET,HOUSING
SN: 65001-UP
1шт.
5
04050-02045
PIN,VALVE
SN: 65001-UP
1шт.
6
130-27-05100
SERVICE KIT,FINAL DRIVE
SN: 65001-UP
2шт.
6
135-27-11141
GASKET,CASE
SN: 65001-UP
1шт.
6
07000-05155
O-RING,CAGE
SN: 65001-UP
1шт.
6
07013-10090
SEAL,OIL, FLANGE
SN: 65001-UP
1шт.
6
130-27-51140
LOCK,NUT
SN: 65001-UP
1шт.
6
145-27-11240
GASKET,NUT
SN: 65001-UP
1шт.
6
135-27-11430
LOCK,HUB
SN: 65001-UP
6шт.
6
130-27-00140
O-RING ASS'Y,GUARD
SN: 65001-UP
1шт.
6
0
O-RING
SN: 65001-UP
2шт.
6
07000-05260
O-RING,GUARD
SN: 65001-UP
1шт.
6
131-27-42121
LOCK,NUT
SN: 65001-UP
1шт.
6
07000-05220
O-RING,CAGE
SN: 65001-UP
1шт.
6
130-27-00161
O-RING ASS'Y,SUPPORT
SN: 65001-UP
1шт.
6
0
O-RING
SN: 65001-UP
2шт.
6
135-27-12320
LOCK,NUT
SN: 65001-UP
1шт.
6
07000-02115
O-RING,CAP
SN: 65001-UP
1шт.
7
131-30-05150
SERVICE KIT,FRONT IDLER
SN: 65001-UP
2шт.
7
07000-03092
O-RING,BUSHING
SN: 65001-UP
2шт.
7
07000-03048
O-RING,SHAFT
SN: 65001-UP
2шт.
7
140-30-00411
O-RING ASS'Y,BUSHING
SN: 65001-UP
2шт.
7
0
O-RING
SN: 65001-UP
2шт.
8
131-30-05160
SERVICE KIT,TRACK ROLLER
SN: 65001-UP
10шт.
8
131-30-05160
SERVICE KIT,TRACK ROLLER
SN: 65000-65000
14шт.
8
131-30-05160
SERVICE KIT,TRACK ROLLER (OP)
SN: 65001-UP
12шт.
8
07000-03092
O-RING,BUSHING
SN: 65001-UP
2шт.
8
07000-03045
O-RING,COLLAR
SN: 65001-UP
2шт.
8
140-30-00411
O-RING ASS'Y,COLLAR
SN: 65001-UP
2шт.
8
0
O-RING
SN: 65001-UP
2шт.
9
131-30-05170
SERVICE KIT,CARRIER ROLLER
SN: 65001-UP
4шт.
9
07000-03048
O-RING,COLLAR
SN: 65001-UP
1шт.
9
130-30-15140
LOCK,PLATE
SN: 65001-UP
1шт.
9
07000-03082
O-RING,COVER
SN: 65001-UP
1шт.
9
140-30-00411
O-RING ASS'Y,COLLAR
SN: 65001-UP
1шт.
9
0
O-RING
SN: 65001-UP
2шт.
10
130-63-05020
SERVICE KIT,BLADE LIFT CYLINDER
SN: 65001-UP
2шт.
10
130-63-12172
PACKING,ROD
SN: 65001-UP
1шт.
10
07000-12085
O-RING,CYLINDER HEAD
SN: 65001-UP
1шт.
10
07146-02086
RING,CYLINDER HEAD
SN: 65001-UP
1шт.
10
07000-03070
O-RING,GLAND
SN: 65001-UP
1шт.
10
07016-00558
SEAL,DUST, GLAND
SN: 65001-UP
1шт.
10
07137-00030
SEAL,DUST, BUSHING
SN: 65001-UP
2шт.
10
07000-03035
O-RING,BUSHING
SN: 65001-UP
2шт.
10
07155-00925
RING,PISTON
SN: 65001-UP
1шт.
10
232-63-12451
PACKING,PISTON
SN: 65001-UP
2шт.
10
07000-13030
O-RING,TUBE
SN: 65001-UP
2шт.
10
07145-00045
SEAL,DUST, CYLINDER
SN: 65001-UP
2шт.
11
130-63-05050
SERVICE KIT,TILT CYLINDER
SN: 65000-65000
1шт.
11
07145-00050
SEAL,DUST, CYLINDER
SN: 65000-65000
2шт.
11
154-63-42373
PACKING,ROD
SN: 65000-65000
1шт.
11
07000-15150
O-RING,CYLINDER HEAD
SN: 65000-65000
1шт.
11
07146-05152
RING,CYLINDER HEAD
SN: 65000-65000
1шт.
11
07000-02090
O-RING,GLAND
SN: 65000-65000
1шт.
11
07016-00708
SEAL,DUST, GLAND
SN: 65000-65000
1шт.
11
141-60-34411
U-PACKING,PISTON
SN: 65000-65000
2шт.
11
07155-01640
RING,PISTON
SN: 65000-65000
1шт.
