Запчасти Komatsu D51EX A8-AA9 КАРТЕР МАХОВИКА

1

6754-21-4210

BOLT

SN: 30910419-UP

2шт.

2

6731-21-6220

BOLT (M10-1.50x80)

SN: 30910419-UP

2шт.

3

6742-01-5504

BOLT (M10-1.50x40)

SN: 30910419-UP

10шт.

4

6736-21-5350

BOLT (M12-1.75x80)

SN: 30910419-UP

6шт.

5

6731-22-1310

SEAL, OIL

SN: 30910419-UP

1шт.

|6

6754-22-4110

HOUSING, FLYWHEEL

SN: 30910419-UP

1шт.

6

6732-11-1920

PLUG, PIPE

SN: 30910419-UP

1шт.

|7

6735-21-4150

PLUG, THREADED

SN: 30910419-UP

1шт.

7

NSS

PLUG, THREADED

SN: 30910419-UP

1шт.

8

6735-21-4160

SEAL, O-RING

SN: 30910419-UP

1шт.

9

6738-22-5110

BRACE, TUBE

SN: 30910419-UP

1шт.

10

6754-22-5610

SPACER, MOUNTING

SN: 30910419-UP

1шт.

11

6732-21-4161

SEAL, O-RING

SN: 30910419-UP

1шт.

12

6732-21-3120

BOLT (M8-1.25x16)

SN: 30910419-UP

1шт.

13

6732-21-6630

BOLT (M8-1.25x30)

SN: 30910419-UP

1шт.

14

6732-21-4130

PLATE, COVER

SN: 30910419-UP

1шт.

15

6732-21-4150

PLUG, O-RING

SN: 30910419-UP

1шт.

16

6742-01-5158

GASKET, COVER PLATE

SN: 30910419-UP

1шт.

17

6754-21-4120

HOUSING, FLYWHEEL

SN: 30910419-UP

1шт.

|$25

SERVICE PARTS

-1шт.

|5

6735-K2-3010

KIT, CRANKSHAFT SEAL

SN: 30910419-UP

1шт.

|5

NSS

TOOL, SEAL INSTALLATION

SN: 30910419-UP

1шт.

5

6731-22-1310

SEAL, OIL

SN: 30910419-UP

1шт.

|5

NSS

TOOL, SEAL INSTALLATION

SN: 30910419-UP

1шт.

|5

NSS

TOOL, SEAL INSTALLATION

SN: 30910419-UP

1шт.
