Запчасти Komatsu D51EX A-AA8 ШАТУН И ПОРШЕНЬ

|1

6737-32-3120

ROD, ENGINE CONNECTING

SN: 30910419-UP

6шт.

1

NSS

ROD, ENGINE CONNECTING

SN: 30910419-UP

1шт.

2

6732-31-3320

BOLT, CONNECTING ROD CAP

SN: 30910419-UP

2шт.

3

6732-31-3132

BUSHING

SN: 30910419-UP

1шт.

4

6754-32-3410

BEARING, CONNECTING (UPPER)

SN: 30910419-UP

6шт.

5

6732-31-3420

BEARING, CONNECTING (LOWER)

SN: 30910419-UP

6шт.

|6

6754-32-2110

KIT, ENGINE PISTON

SN: 30910419-UP

6шт.

6

NSS

PISTON

SN: 30910419-UP

1шт.

7

6754-31-2410

PIN, PISTON

SN: 30910419-UP

1шт.

8

6754-31-2010

SET, PISTON RING

SN: 30910419-UP

1шт.

|8

NSS

RING, COMPRESSION PISTON (TOP)

SN: 30910419-UP

1шт.

|8

NSS

RING, COMPRESSION PISTON (2ND)

SN: 30910419-UP

1шт.

|8

6754-31-2231

RING, OIL PISTON

SN: 30910419-UP

1шт.

9

6732-31-2420

RING, RETAINING

SN: 30910419-UP

12шт.

10

6754-21-1190

NOZZLE, PISTON COOLING

SN: 30910419-UP

6шт.

11

6754-21-1180

BOLT

SN: 30910419-UP

6шт.

|$25

SERVICE PARTS

-1шт.

4

6754-32-3420

BEARING, CONNECTING ROD (0.25MM OS)

SN: 30910419-UP

-2шт.

4

6754-32-3430

BEARING, CONNECTING ROD (0.50MM OS)

SN: 30910419-UP

-2шт.

4

6754-32-3440

BEARING, CONNECTING ROD (0.75MM OS)

SN: 30910419-UP

-2шт.

4

6754-32-3450

BEARING, CONNECTING ROD (1.00MM OS)

SN: 30910419-UP

-2шт.

5

6738-39-3400

BEARING, CONNECTING ROD (0.25MM OS)

SN: 30910419-UP

-2шт.

5

6738-38-3400

BEARING, CONNECTING ROD (0.50MM OS)

SN: 30910419-UP

-2шт.

5

6738-37-3400

BEARING, CONNECTING ROD (0.75MM OS)

SN: 30910419-UP

-2шт.

5

6738-36-3400

BEARING, CONNECTING ROD (1.00MM OS)

SN: 30910419-UP

-2шт.
