Запчасти Komatsu D50P-18 МАРКИРОВКА (ЯПОН.)(№87-) МАРКИРОВКА

|1

134-98-11210

PLATE KIT

SN: 84007-UP

1шт.

1

0

PLATE¤ SAFETY,BEFORE OPERATING

SN: 84007-UP

1шт.

2

0

PLATE¤ CAUTION,BEFORE AND AFTER OPERATION

SN: 84007-UP

1шт.

3

0

PLATE¤ SAFETY,RADIATOR WARNING

SN: 84007-UP

1шт.

4

0

PLATE¤ SAFETY,HYDRAULIC TANK

SN: 84007-UP

1шт.

5

0

PLATE¤ CAUTION,SAFETY COMFIRM OF REAR

SN: 84007-UP

1шт.

6

14X-98-11161

PLATE¤ SAFETY,ADJUSTING TRACK SHOE

SN: 84007-UP

2шт.

7

09650-01101

PLATE¤ INSTRUCTION,RADIATOR

SN: 83001-UP

1шт.

8

130-54-75110

PLATE¤ OPERATING,TRANSMISSION CONTROL LEVER

SN: 84002-UP

1шт.

9

120-54-32451

SHEET,ANTISKID

SN: 83001-UP

2шт.

10

13F-98-31110

GRILLE,BLADE CONTROL LEVER (PTP)

SN: 84058-UP

1шт.

|10

12F-54-45310

PLATE¤ OPERATING,BLADE CONTROL LEVER (PTP)

SN: 83001-84057

1шт.

11

09656-01080

PLATE¤ INSTRUCTION,FUEL TANK STRAINER

SN: 83001-UP

1шт.

12

09687-32570

PLATE¤ OPERATING,MAIN CLUTCH

SN: 83001-UP

1шт.

13

09652-01101

PLATE¤ CAUTION,FUEL TANK

SN: 83001-UP

1шт.

14

13F-54-35350

PLATE¤ MARK,D50P

SN: 83823-UP

1шт.

15

09655-01120

PLATE¤ INSTRUCTION,OIL FILTER

SN: 83001-UP

1шт.

16

134-54-55142

PLATE¤ MARK

SN: 83823-UP

2шт.

17

15B-54-15151

PLATE¤ MARK,LINE¤ L.H.

SN: 83269-UP

1шт.

|17

15B-54-15141

PLATE¤ MARK,LINE¤ R.H.

SN: 83269-UP

1шт.

18

130-54-85110

CHART,OIL

SN: 83001-UP

1шт.

19

13F-54-35350

PLATE¤ MARK,D50P

SN: 83823-UP

1шт.

20

21K-00-22170

PLATE¤ MARK,SYMBOL

SN: 83001-UP

1шт.

21

144-54-84122

PLATE¤ MARK,WHITE LINE

SN: 83834-UP

3шт.

22

09690-C0400

PLATE¤ MARK,KOMATSU

SN: 83823-UP

1шт.

23

09683-0000F

PLATE¤ OPERATING,STARTING SWITCH

SN: 84058-UP

1шт.

|23

09683-01060

PLATE¤ OPERATING,STARTING SWITCH

SN: 83001-84057

1шт.

24

09602-01635

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 83001-UP

1шт.

|24

04418-13060

SCREW

SN: 83001-UP

4шт.

25

13F-54-35130

PLATE¤ DATA

SN: 83001-UP

1шт.

26

09685-00005

PLATE¤ OPERATING,BLADE CONTROL LEVER LOCK

SN: 83001-UP

1шт.

27

09685-00004

PLATE¤ OPERATING,BRAKE LOCK LEVER

SN: 83001-UP

1шт.

28

09690-C0280

PLATE¤ MARK,KOMATSU

SN: 83823-UP

1шт.

29

21X-98-21190

TAG¤ CAUTION,DO NOT OPERATE

SN: 84007-UP

1шт.

30

09679-0200B

PLATE¤ OPERATING,HORN SWITCH

SN: 84058-UP

1шт.

31

134-98-31370

PLATE¤ CAUTION,IMAGE

SN: 84058-UP

1шт.

32

134-98-31810

PLATE¤ OPERATING,FUEL LEVER

SN: 84058-UP

1шт.
