Артикул
Название
Примечание
Количество
|1
6150-71-1113
INJECTION PUMP A.
SN: 37408-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090800-8431
GOVERNOR ASS'Y
SN: 37408-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.
-1шт.
1
ND190890-0130
COVER
SN: 37408-UP
1шт.
2
ND091031-0150
NUT,CAP
SN: 37408-UP
1шт.
3
ND091006-0150
SCREW
SN: 37408-UP
1шт.
4
ND090944-0310
BUSHING
SN: 37408-UP
1шт.
6
ND090991-0010
PLUG
SN: 37408-UP
2шт.
7
ND090560-0200
CAPSULE,FULL STOP
SN: 37408-UP
1шт.
8
ND090923-0060
NUT,LOCK
SN: 37408-UP
1шт.
9
ND090880-0120
LEVER,SWIVEL
SN: 37408-UP
1шт.
10
ND090892-0150
BUSHING
SN: 37408-UP
2шт.
12
ND949071-0090
WASHER,SNAP
SN: 37408-UP
2шт.
13
ND949047-1760
BOLT
SN: 37408-UP
4шт.
14
ND949047-1750
BOLT
SN: 37408-UP
2шт.
16
ND091071-1420
LEVER,ADJUST
SN: 37408-UP
1шт.
17
ND091071-2661
LEVER,ADJUST
SN: 37408-UP
1шт.
18
ND949047-1190
BOLT
SN: 37408-UP
1шт.
20
ND949047-1790
BOLT
SN: 37408-UP
2шт.
21
ND091051-0480
PLATE
SN: 37408-UP
1шт.
22
ND91418-06141
BOLT
SN: 37408-UP
2шт.
23
ND91418-06161
BOLT
SN: 37408-UP
2шт.
24
ND090241-0010
WASHER¤ 1.6MM
SN: 37408-UP
2шт.
25
ND091031-0030
NUT,CAP
SN: 37408-UP
1шт.
26
ND949062-1650
PACKING
SN: 37408-UP
1шт.
27
ND949130-0030
KEY
SN: 37408-UP
1шт.
29
ND949013-8210
WASHER¤ 0.3MM
SN: 37408-UP
-2шт.
|29
ND949013-8220
WASHER¤ 0.6MM
SN: 37408-UP
-2шт.
|29
ND949013-8230
WASHER¤ 0.9MM
SN: 37408-UP
-2шт.
30
ND949050-1020
NUT
SN: 37408-UP
1шт.
31
ND949018-1020
WASHER¤ 1.0MM
SN: 37408-UP
2шт.
|1
6150-71-1113
INJECTION PUMP A.
SN: 37408-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
ND090800-8431
GOVERNOR ASS'Y
SN: 37408-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.
-1шт.
1
ND190890-0130
COVER
SN: 37408-UP
1шт.
2
ND091031-0150
NUT,CAP
SN: 37408-UP
1шт.
3
ND091006-0150
SCREW
SN: 37408-UP
1шт.
4
ND090944-0310
BUSHING
SN: 37408-UP
1шт.
6
ND090991-0010
PLUG
SN: 37408-UP
2шт.
7
ND090560-0200
CAPSULE,FULL STOP
SN: 37408-UP
1шт.
8
ND090923-0060
NUT,LOCK
SN: 37408-UP
1шт.
9
ND090880-0120
LEVER,SWIVEL
SN: 37408-UP
1шт.
10
ND090892-0150
BUSHING
SN: 37408-UP
2шт.
12
ND949071-0090
WASHER,SNAP
SN: 37408-UP
2шт.
13
ND949047-1760
BOLT
SN: 37408-UP
4шт.
14
ND949047-1750
BOLT
SN: 37408-UP
2шт.
16
ND091071-1420
LEVER,ADJUST
SN: 37408-UP
1шт.
17
ND091071-2661
LEVER,ADJUST
SN: 37408-UP
1шт.
18
ND949047-1190
BOLT
SN: 37408-UP
1шт.
20
ND949047-1790
BOLT
SN: 37408-UP
2шт.
21
ND091051-0480
PLATE
SN: 37408-UP
1шт.
22
ND91418-06141
BOLT
SN: 37408-UP
2шт.
23
ND91418-06161
BOLT
SN: 37408-UP
2шт.
24
ND090241-0010
WASHER¤ 1.6MM
SN: 37408-UP
2шт.
25
ND091031-0030
NUT,CAP
SN: 37408-UP
1шт.
26
ND949062-1650
PACKING
SN: 37408-UP
1шт.
27
ND949130-0030
KEY
SN: 37408-UP
1шт.
29
ND949013-8210
WASHER¤ 0.3MM
SN: 37408-UP
-2шт.
|29
ND949013-8220
WASHER¤ 0.6MM
SN: 37408-UP
-2шт.
|29
ND949013-8230
WASHER¤ 0.9MM
SN: 37408-UP
-2шт.
30
ND949050-1020
NUT
SN: 37408-UP
1шт.
31
ND949018-1020
WASHER¤ 1.0MM
SN: 37408-UP
2шт.
Выбрано товаров: 78
