Запчасти Komatsu 6D125-1A ТОПЛ. НАСОС (РЕГУЛЯТОР) (/)(№78-) ТОПЛИВН. СИСТЕМА

Схема запчастей Komatsu 6D125-1A - ТОПЛ. НАСОС (РЕГУЛЯТОР) (/)(№78-) ТОПЛИВН. СИСТЕМА
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33

Артикул

Название

Примечание

Количество

|1

6150-71-1113

INJECTION PUMP A.

SN: 37408-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND090800-8431

GOVERNOR ASS'Y

SN: 37408-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.

-1шт.

1

ND090810-0390

HOUSING

SN: 37408-UP

1шт.

2

ND090878-0040

PLATE

SN: 37408-UP

1шт.

3

ND091024-0031

SCREW,ADJUST

SN: 37408-UP

2шт.

4

ND090901-0200

LEVER ASS'Y,TENSION

SN: 37408-UP

1шт.

5

ND090930-0490

LEVER ASS'Y,CONTROL

SN: 37408-UP

1шт.

6

ND090894-0010

E-RING

SN: 37408-UP

1шт.

7

ND948053-0051

NUT

SN: 37408-UP

2шт.

8

ND091046-0010

SLIDER

SN: 37408-UP

1шт.

9

ND090970-0350

SHACKLE ASS'Y

SN: 37408-UP

1шт.

10

ND949130-0050

KEY

SN: 37408-UP

1шт.

11

ND090840-0520

FLYWEIGHT ASS'Y

SN: 37408-UP

1шт.

12

ND949015-0500

WASHER¤ 2.5MM,SPRING

SN: 37408-UP

1шт.

13

ND090844-0010

NUT

SN: 37408-UP

1шт.

14

ND090860-0200

SLEEVE SUB ASS'Y

SN: 37408-UP

1шт.

15

ND090868-0040

PLATE,THRUST

SN: 37408-UP

1шт.

16

ND90567-30000

RING,SNAP

SN: 37408-UP

2шт.

17

ND949013-4090

WASHER¤ 0.1MM

SN: 37408-UP

-2шт.

|17

ND949013-4060

WASHER¤ 0.2MM

SN: 37408-UP

-2шт.

|17

ND949013-4070

WASHER¤ 0.3MM

SN: 37408-UP

-2шт.

|17

ND949013-4080

WASHER¤ 0.4MM

SN: 37408-UP

-2шт.

|17

ND949013-4100

WASHER¤ 1.0MM

SN: 37408-UP

-2шт.

18

ND090992-0480

SPRING,SPEED CONTROL

SN: 37408-UP

1шт.

19

ND090993-0290

SPRING,START

SN: 37408-UP

1шт.

|20

ND090910-1770

ADAPTER ASS'Y

SN: 37408-UP

1шт.

20

ND090911-0010

SCREW,ADJUST

SN: 37408-UP

1шт.

21

ND090919-0010

ADAPTER

SN: 37408-UP

1шт.

22

ND090918-0380

SPRING

SN: 37408-UP

1шт.

23

ND090894-0010

E-RING

SN: 37408-UP

1шт.

24

ND949013-3880

WASHER¤ 0.1MM

SN: 37408-UP

-2шт.

|24

ND949013-4040

WASHER¤ 0.2MM

SN: 37408-UP

-2шт.

|24

ND949013-4030

WASHER¤ 0.5MM

SN: 37408-UP

-2шт.

|24

ND949013-7880

WASHER¤ 1.0MM

SN: 37408-UP

-2шт.

25

ND090923-0011

NUT,LOCK

SN: 37408-UP

1шт.

26

ND090224-0140

PLUG

SN: 37408-UP

1шт.

27

ND090119-0040

GASKET

SN: 37408-UP

1шт.

28

ND090823-0230

GASKET

SN: 37408-UP

1шт.

29

ND090245-0230

SCREW

SN: 37408-UP

1шт.

30

ND090222-0120

WASHER

SN: 37408-UP

2шт.

31

ND949047-0620

BOLT

SN: 37408-UP

2шт.

32

ND91418-06201

BOLT

SN: 37408-UP

2шт.

33

ND91518-06161

BOLT

SN: 37408-UP

4шт.

|1

6150-71-1113

INJECTION PUMP A.

SN: 37408-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$3

THE DENSO PART NUMBER IS THAT ND IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

ND090800-8431

GOVERNOR ASS'Y

SN: 37408-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.

-1шт.

1

ND090810-0390

HOUSING

SN: 37408-UP

1шт.

2

ND090878-0040

PLATE

SN: 37408-UP

1шт.

3

ND091024-0031

SCREW,ADJUST

SN: 37408-UP

2шт.

4

ND090901-0200

LEVER ASS'Y,TENSION

SN: 37408-UP

1шт.

5

ND090930-0490

LEVER ASS'Y,CONTROL

SN: 37408-UP

1шт.

6

ND090894-0010

E-RING

SN: 37408-UP

1шт.

7

ND948053-0051

NUT

SN: 37408-UP

2шт.

8

ND091046-0010

SLIDER

SN: 37408-UP

1шт.

9

ND090970-0350

SHACKLE ASS'Y

SN: 37408-UP

1шт.

10

ND949130-0050

KEY

SN: 37408-UP

1шт.

11

ND090840-0520

FLYWEIGHT ASS'Y

SN: 37408-UP

1шт.

12

ND949015-0500

WASHER¤ 2.5MM,SPRING

SN: 37408-UP

1шт.

13

ND090844-0010

NUT

SN: 37408-UP

1шт.

14

ND090860-0200

SLEEVE SUB ASS'Y

SN: 37408-UP

1шт.

15

ND090868-0040

PLATE,THRUST

SN: 37408-UP

1шт.

16

ND90567-30000

RING,SNAP

SN: 37408-UP

2шт.

17

ND949013-4090

WASHER¤ 0.1MM

SN: 37408-UP

-2шт.

|17

ND949013-4060

WASHER¤ 0.2MM

SN: 37408-UP

-2шт.

|17

ND949013-4070

WASHER¤ 0.3MM

SN: 37408-UP

-2шт.

|17

ND949013-4080

WASHER¤ 0.4MM

SN: 37408-UP

-2шт.

|17

ND949013-4100

WASHER¤ 1.0MM

SN: 37408-UP

-2шт.

18

ND090992-0480

SPRING,SPEED CONTROL

SN: 37408-UP

1шт.

19

ND090993-0290

SPRING,START

SN: 37408-UP

1шт.

|20

ND090910-1770

ADAPTER ASS'Y

SN: 37408-UP

1шт.

20

ND090911-0010

SCREW,ADJUST

SN: 37408-UP

1шт.

21

ND090919-0010

ADAPTER

SN: 37408-UP

1шт.

22

ND090918-0380

SPRING

SN: 37408-UP

1шт.

23

ND090894-0010

E-RING

SN: 37408-UP

1шт.

24

ND949013-3880

WASHER¤ 0.1MM

SN: 37408-UP

-2шт.

|24

ND949013-4040

WASHER¤ 0.2MM

SN: 37408-UP

-2шт.

|24

ND949013-4030

WASHER¤ 0.5MM

SN: 37408-UP

-2шт.

|24

ND949013-7880

WASHER¤ 1.0MM

SN: 37408-UP

-2шт.

25

ND090923-0011

NUT,LOCK

SN: 37408-UP

1шт.

26

ND090224-0140

PLUG

SN: 37408-UP

1шт.

27

ND090119-0040

GASKET

SN: 37408-UP

1шт.

28

ND090823-0230

GASKET

SN: 37408-UP

1шт.

29

ND090245-0230

SCREW

SN: 37408-UP

1шт.

30

ND090222-0120

WASHER

SN: 37408-UP

2шт.

31

ND949047-0620

BOLT

SN: 37408-UP

2шт.

32

ND91418-06201

BOLT

SN: 37408-UP

2шт.

33

ND91518-06161

BOLT

SN: 37408-UP

4шт.

Выбрано товаров: 92
