Запчасти Komatsu D500E Turbo ОПОРНЫЙ КАТОК ТРАНСМИССИЯ И ЗАДН. МОСТ

1

2983613M91

TRACK ROLLER

EnglischBem: 1 FLANGE

1шт.

2

2983614M91

TRACK ROLLER

EnglischBem: 2 FLANGE

1шт.

3

3079649M1

PLUG

EnglischBem: NOTE: Pos. (3) included in Pos. (1) and (2) Kit 2 FLASQUE

1шт.

4

3079648M1

O-RING

EnglischBem: NOTE: Pos. (4) included in Pos. (1) and (2) Kit 2 FLASQUE

1шт.

5

1421037M1

CIRCLIP

EnglischBem: NOTE: Pos. (5) included in Pos. (1) and (2) Kit 2 FLASQUE

4шт.

6

1421027M1

O-RING

EnglischBem: NOTE: Pos. (6) included in Pos. (1) and (2) Kit 2 FLASQUE

2шт.

7

1421039M1

TAB WASHER

EnglischBem: NOTE: Pos. (7) included in Pos. (1) and (2) Kit 2 FLASQUE

6шт.

8

1421029M1

SCREW

EnglischBem: NOTE: Pos. (8) included in Pos. (1) and (2) Kit 2 FLASQUE

12шт.

9

1421036M1

O-RING

EnglischBem: NOTE: Pos. (9) included in Pos. (1) and (2) Kit 2 FLASQUE

2шт.

10

1430357M91

SEAL KIT

DeutschDesc: DICHTRINGSATZ

1шт.

11

1421015M1

GASKET

EnglischBem: NOTE: Pos. (11) included in Pos. (1) and (2) Kit 2 FLASQUE

4шт.

12

1421033M1

WOODRUFF KEY

EnglischBem: NOTE: Pos. (12) included in Pos. (1) and (2) Kit 2 FLASQUE

1шт.
