Запчасти Komatsu D500E Turbo ЛЕНИВЕЦ ТРАНСМИССИЯ И ЗАДН. МОСТ

1

2983611M91

IDLER

DeutschDesc: LEITRAD

2шт.

2

2983689M1

AXLE

EnglischBem: NOTE: Pos.(2) included in Pos.(14) Kit

1шт.

3

1444792X1

O-RING

EnglischBem: NOTE: Pos.(3) included in Pos.(14) Kit

2шт.

4

3001419X1

ROLLER BEARING

EnglischBem: NOTE: Pos.(4) included in Pos.(14) Kit

2шт.

5

2983678M1

RING

EnglischBem: NOTE: Pos.(5) included in Pos.(14) Kit

4шт.

6

2999891M1

GASKET

EnglischBem: NOTE: Pos.(6) included in Pos.(14) Kit

2шт.

7

2983690M1

TUBE

EnglischBem: NOTE: Pos.(7) included in Pos.(14) Kit

2шт.

8

339806X1

ADAPTER SLEEVES

EnglischBem: NOTE: Pos.(8) included in Pos.(14) Kit

1шт.

9

2909511M1

DISC

EnglischBem: THICKNESS 0,5 MM NOTE: Pos.(9) included in Pos.(14) Kit

-26шт.

10

2909509M1

DISC

EnglischBem: THICKNESS 0,4 MM NOTE: Pos.(10) included in Pos.(14) Kit

-26шт.

11

2909510M1

DISC

EnglischBem: THICKNESS 0,3 MM NOTE: Pos.(11) included in Pos.(14) Kit

-26шт.

12

2983691M1

THRUST PLATE

EnglischBem: NOTE: Pos.(12) included in Pos.(14) Kit

1шт.

13

1444098X1

SCREW

EnglischBem: NOTE: Pos.(13) included in Pos.(14) Kit

1шт.

14

3256001M91

REPAIR KIT

DeutschDesc: REPARATURSATZ

1шт.

15

3000865X1

ADAPTER SLEEVES

DeutschDesc: SPANNHUELSE

1шт.

16

3000864X1

ADAPTER SLEEVES

DeutschDesc: SPANNHUELSE

1шт.
