Запчасти Komatsu D475A-5 ОТВАЛ (УСИЛ. И SUPER DOZER) РАБОЧЕЕ ОБОРУДОВАНИЕ

1

198-72-65310

BLADE

SN: 20001-UP

1шт.

2

198-72-51170

PLATE (WELDED)

SN: 20001-UP

2шт.

3

198-72-51180

PLATE,L.H. (WELDED)

SN: 20001-UP

1шт.

4

198-72-51190

PLATE,R.H. (WELDED)

SN: 20001-UP

1шт.

5

198-72-51210

PLATE,L.H. (WELDED)

SN: 20001-UP

1шт.

6

198-72-51220

PLATE,R.H. (WELDED)

SN: 20001-UP

1шт.

7

198-72-51230

PLATE,L.H. (WELDED)

SN: 20001-UP

1шт.

8

198-72-51240

PLATE,R.H. (WELDED)

SN: 20001-UP

1шт.

9

198-72-51251

BRACKET (WELDED)

SN: 20001-UP

1шт.

10

198-72-51260

PLATE (WELDED)

SN: 20001-UP

2шт.

11

198-72-51830

BRACKET,L.H. (WELDED)

SN: 20001-UP

1шт.

12

198-72-51840

BRACKET,R.H. (WELDED)

SN: 20001-UP

1шт.

13

198-72-65330

BRACKET,L.H. (WELDED)

SN: 20001-UP

1шт.

14

198-72-65340

BRACKET,R.H. (WELDED)

SN: 20001-UP

1шт.

15

198-72-65350

BRACKET (WELDED)

SN: 20001-UP

2шт.

16

198-72-65360

PLATE (WELDED)

SN: 20001-UP

2шт.

17

198-72-51450

PLATE (WELDED)

SN: 20001-UP

2шт.

18

198-72-51460

PLATE (WELDED)

SN: 20001-UP

1шт.

19

198-72-51470

PLATE (WELDED)

SN: 20001-UP

1шт.

20

198-72-51510

PLATE (WELDED)

SN: 20001-UP

1шт.

21

198-72-51520

PLATE (WELDED)

SN: 20001-UP

1шт.

22

198-72-51550

PLATE (WELDED)

SN: 20001-UP

1шт.

23

198-72-51560

PLATE (WELDED)

SN: 20001-UP

1шт.

24

198-72-51850

PLATE (WELDED)

SN: 20001-UP

2шт.

25

198-72-51940

PLATE (WELDED)

SN: 20001-UP

2шт.

26

198-72-51960

PLATE (WELDED)

SN: 20001-UP

1шт.

27

198-72-51970

PLATE (WELDED)

SN: 20001-UP

1шт.

28

198-72-51980

PLATE (WELDED)

SN: 20001-UP

1шт.

29

198-72-51990

PLATE (WELDED)

SN: 20001-UP

1шт.

30

198-72-51810

PIN

SN: 20001-UP

2шт.

31

09257-11219

LOCK

SN: 20001-UP

2шт.

32

01010-82460

BOLT

SN: 20001-UP

8шт.

33

01643-32460

WASHER

SN: 20001-UP

8шт.

34

198-72-51720

PIN

SN: 20001-UP

2шт.

35

09257-09014

LOCK

SN: 20001-UP

2шт.

36

01010-82045

BOLT

SN: 20001-UP

8шт.

37

01643-32060

WASHER

SN: 20001-UP

8шт.

38

198-72-51820

PIN

SN: 20001-UP

1шт.

39

01010-82470

BOLT

SN: 20001-UP

8шт.

40

01643-32460

WASHER

SN: 20001-UP

8шт.

41

198-72-51880

PLATE

SN: 20001-UP

2шт.

42

19M-72-11621

BUSHING

SN: 20001-UP

2шт.

43

19M-30-14360

BUSHING

SN: 20001-UP

2шт.

44

198-72-51380

BUSHING

SN: 20001-UP

2шт.

45

17M-21-25111

BUSHING

SN: 20001-UP

4шт.

46

198-72-51121

BRACKET

SN: 20001-UP

1шт.

47

198-71-00340

SHIM ASS'Y

SN: 20001-UP

2шт.

|47

0

SHIM¤ 2.0MM

SN: 20001-UP

4шт.

|47

0

SHIM¤ 1.0MM

SN: 20001-UP

8шт.

|47

0

SHIM¤ 0.5MM

SN: 20001-UP

8шт.

48

01011-83335

BOLT

SN: 20001-UP

16шт.

49

01643-33380

WASHER

SN: 20001-UP

16шт.

50

07020-00000

FITTING

SN: 20001-UP

2шт.

51

07049-02430

PLUG

SN: 20001-UP

1шт.

52

198-71-31540

EDGE

SN: 20001-UP

2шт.

53

198-71-31550

EDGE

SN: 20001-UP

3шт.

54

198-71-21850

BOLT

SN: 20001-UP

34шт.

55

198-71-21890

WASHER

SN: 20001-UP

34шт.

56

198-71-21911

NUT

SN: 20001-UP

34шт.

57

198-71-31520

BIT

SN: 20001-UP

1шт.

58

198-71-21870

BOLT

SN: 20001-UP

8шт.

59

198-71-21880

BOSS

SN: 20001-UP

8шт.

60

198-71-21911

NUT

SN: 20001-UP

8шт.

61

198-71-31530

BIT

SN: 20001-UP

1шт.

62

198-71-21860

BOLT

SN: 20001-UP

8шт.

63

198-71-21890

WASHER

SN: 20001-UP

8шт.

64

198-71-21911

NUT

SN: 20001-UP

8шт.
