Запчасти Komatsu D475A-2 МАРКИРОВКА (ПОРТУГАЛ.)(№98-) МАРКИРОВКА¤ ИНСТРУМЕНТ И РЕМКОМПЛЕКТЫ

1

09650-21101

PLATE, INSTRUCTION,RADIATOR WATER LEVEL

SN: 10398-UP

1шт.

2

14X-98-11730

PLATE, SAFETY,RADIATOR CAP

SN: 10398-UP

1шт.

3

14X-98-11720

PLATE, SAFETY,HYDRAULIC OIL TANK

SN: 10398-UP

1шт.

4

09655-21120

PLATE, INSTRUCTION,OIL FILTER

SN: 10398-UP

1шт.

5

09652-21101

PLATE, CAUTION,FUEL TANK

SN: 10398-UP

1шт.

6

09656-21080

PLATE, INSTRUCTION,FUEL TANK STRAINER

SN: 10398-UP

1шт.

7

198-98-41320

PLATE

SN: 10398-UP

1шт.

8

198-98-41310

STRIPE

SN: 10398-UP

1шт.

9

198-98-41360

STRIPE

SN: 10398-UP

1шт.

10

09960-01001

PLATE, MARK

SN: 10398-UP

2шт.

11

198-98-41371

STRIPE,L.H.

SN: 10398-UP

1шт.

12

198-98-41170

STRIPE

SN: 10398-UP

2шт.

13

198-98-41180

STRIPE,L.H.

SN: 10398-UP

1шт.

14

198-98-41260

STRIPE,L.H.

SN: 10398-UP

1шт.

15

198-98-41210

STRIPE,L.H.

SN: 10398-UP

1шт.

16

09620-20200

PLATE, NAME,ROPS (EXCEPT USA, CANADA)

SN: 10398-UP

1шт.

16

04418-13060

SCREW

SN: 10398-UP

4шт.

17

198-98-41220

STRIPE,L.H.

SN: 10398-UP

1шт.

18

198-98-41270

STRIPE,L.H.

SN: 10398-UP

1шт.

19

09960-01001

PLATE, MARK

SN: 10398-UP

2шт.

20

09601-50000

PLATE, NAME,RIPPER (LIMITED SUPPLY)

SN: 10398-UP

1шт.

20

04418-13060

SCREW

SN: 10398-UP

4шт.

21

09960-01012

PLATE, MARK

SN: 10398-UP

2шт.

22

195-98-22961

PLATE, CAUTION,TRACK ADJUSTING

SN: 10398-UP

2шт.

22

01220-60408

SCREW

SN: 10398-UP

6шт.

23

198-98-41191

STRIPE,L.H.

SN: 10398-UP

1шт.

24

09690-C0710

PLATE, MARK,FUEL TANK, REAR FACE

SN: 10398-UP

1шт.

25

09601-50000

PLATE, NAME,BLADE (LIMITED SUPPLY)

SN: 10398-UP

1шт.

25

04418-13060

SCREW

SN: 10398-UP

4шт.

26

198-98-41251

STRIPE,R.H.

SN: 10398-UP

1шт.

27

198-98-41240

STRIPE

SN: 10398-UP

1шт.

28

198-98-41230

STRIPE,R.H.

SN: 10398-UP

1шт.

29

198-98-41381

STRIPE,R.H.

SN: 10398-UP

1шт.

30

198-98-41340

STRIPE,R.H.

SN: 10398-UP

1шт.

31

198-98-41350

STRIPE,R.H.

SN: 10398-UP

1шт.

32

198-98-41280

STRIPE

SN: 10398-UP

2шт.

33

198-98-41290

STRIPE,L.H.

SN: 10398-UP

1шт.

34

09666-02000

PLATE, SAFETY,FIRE PREVENTION

SN: 10398-UP

1шт.

35

09649-02001

PLATE, INSTRUCTION,ENGINE STOP

SN: 10398-UP

1шт.

36

198-98-41920

PLATE,LUBRICATION

SN: 10398-UP

1шт.

37

09173-02000

PLATE, SAFETY,CHECK

SN: 10398-UP

1шт.

38

195-98-12980

PLATE, CAUTION,SEAT BELT

SN: 10398-UP

1шт.

39

09602-00000

PLATE, NAME,MACHINE (LIMITED SUPPLY)

SN: 10398-UP

1шт.

39

04418-13060

SCREW

SN: 10398-UP

4шт.

40

09685-00001

PLATE, OPERATING,LOCK LEVER

SN: 10398-UP

1шт.

41

175-900-2262

PLATE, CAUTION,TRAVELING ON SLOPE

SN: 10398-UP

1шт.

42

14X-98-11740

PLATE, CAUTION

SN: 10398-UP

1шт.

43

09685-00002

PLATE, OPERATING,LOCK LEVER

SN: 10398-UP

1шт.

44

09667-02000

PLATE, SAFETY,ENGINE SIDE COVER

SN: 10398-UP

1шт.

45

09651-02001

PLATE, SAFETY,BEFORE OPERATING

SN: 10398-UP

1шт.

46

195-98-21190

PLATE, OPERATING,HORN SWITCH

SN: 10398-UP

1шт.

47

195-98-24540

PLATE, MARK,SYMBOL

SN: 10398-UP

1шт.

48

195-98-21150

PLATE, OPERATING,RIPPER

SN: 10398-UP

1шт.

49

17M-98-21520

PLATE, OPERATING,LOCK LEVER, RIPPER

SN: 10398-UP

1шт.

50

17M-98-21520

PLATE, OPERATING,LOCK LEVER, BLADE

SN: 10398-UP

1шт.

51

195-98-21140

PLATE, OPERATING,BLADE CONTROL LEVER

SN: 10398-UP

1шт.

52

17M-98-21510

PLATE, OPERATING,PIN PULLER

SN: 10398-UP

1шт.

53

198-98-41330

STRIPE

SN: 10398-UP

1шт.

54

198-98-41310

STRIPE

SN: 10398-UP

1шт.

55

195-98-25190

PLATE, CAUTION,DAMPER LUBRICATION

SN: 10398-UP

1шт.

56

09628-90195

PLATE, MARK,ROPS

SN: 10398-UP

1шт.

57

09629-90215

PLATE, MARK,ROPS

SN: 10398-UP

1шт.

58

17A-98-11730

PLATE, CAUTION

SN: 10398-UP

2шт.

59

09690-M0063

PLATE, MARK

SN: 10398-UP

1шт.
