Артикул
Название
Примечание
Количество
|$0
6164-71-1312
INJECTION PUMP ASS'Y
SN: 10445-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A TO 0491A.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105235-1791
FEED PUMP ASS'Y
SN: 10445-UP
1шт.
1
DK152002-2220
HOUSING,FEED PUMP
SN: 10445-UP
1шт.
2
DK152100-1120
PISTON
SN: 10445-UP
1шт.
3
DK152104-0400
SPRING,PISTON
SN: 10445-UP
1шт.
4
DK152105-1500
PLUG
SN: 10445-UP
1шт.
5
DK152111-4620
TAPPET ASS'Y
SN: 10445-UP
1шт.
6
DK152115-0500
VALVE
SN: 10445-UP
4шт.
8
DK152117-0400
PLUG
SN: 10445-UP
2шт.
9
DK152118-1000
ADAPTER
SN: 10445-UP
1шт.
11
DK152121-0200
RING,SNAP
SN: 10445-UP
1шт.
13
DK152300-3620
BOLT,EYE
SN: 10445-UP
1шт.
14
DK134045-0100
PLUG
SN: 10445-UP
1шт.
16
DK132400-0200
ADAPTER
SN: 10445-UP
1шт.
18
DK029731-4680
BOLT,EYE
SN: 10445-UP
1шт.
|$0
6164-71-1312
INJECTION PUMP ASS'Y
SN: 10445-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451A TO 0491A.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105235-1791
FEED PUMP ASS'Y
SN: 10445-UP
1шт.
1
DK152002-2220
HOUSING,FEED PUMP
SN: 10445-UP
1шт.
2
DK152100-1120
PISTON
SN: 10445-UP
1шт.
3
DK152104-0400
SPRING,PISTON
SN: 10445-UP
1шт.
4
DK152105-1500
PLUG
SN: 10445-UP
1шт.
5
DK152111-4620
TAPPET ASS'Y
SN: 10445-UP
1шт.
6
DK152115-0500
VALVE
SN: 10445-UP
4шт.
8
DK152117-0400
PLUG
SN: 10445-UP
2шт.
9
DK152118-1000
ADAPTER
SN: 10445-UP
1шт.
11
DK152121-0200
RING,SNAP
SN: 10445-UP
1шт.
13
DK152300-3620
BOLT,EYE
SN: 10445-UP
1шт.
14
DK134045-0100
PLUG
SN: 10445-UP
1шт.
16
DK132400-0200
ADAPTER
SN: 10445-UP
1шт.
18
DK029731-4680
BOLT,EYE
SN: 10445-UP
1шт.
Выбрано товаров: 46
