Запчасти Komatsu D41PF-6 МАРКИРОВКА МАРКИРОВКА

1

14X-98-11170

PLATE¤ OPERATING,LOCK

SN: B29001-UP

2шт.

2

12G-98-51220

PLATE¤ OPERATING,STEERING LEVER (C AND B)

SN: B29001-UP

1шт.

3

09690-B0224

PLATE¤ MARK,KOMATSU¤ FRONT

SN: B29001-UP

1шт.

4

124-98-51140

PLATE¤ OPERATING,WORK EQUIP.LEVER (PAT DOZER)

SN: B29001-UP

1шт.

5

17A-98-11180

PLATE,HORN

SN: B29001-UP

1шт.

6

12G-98-51230

PLATE¤ OPERATING,REAR HYDRAULIC

SN: B29001-UP

1шт.

7

12G-98-51240

PLATE¤ OPERATING,REAR HYDRAULIC

SN: B29001-UP

1шт.

8

09675-00001

PLATE¤ OPERATING,3-POINT HITCH

SN: B29001-UP

1шт.

9

09672-0000C

PLATE¤ OPERATING,REAR PTO

SN: B29001-UP

1шт.

|10

14X-98-11111

PLATE

SN: B29001-UP

1шт.

10

0

PLATE¤ SAFETY

SN: B29001-UP

1шт.

11

0

PLATE¤ SAFETY

SN: B29001-UP

1шт.

12

0

PLATE¤ CAUTION,BEFORE AND AFTER OPERATION

SN: B29001-UP

1шт.

13

0

PLATE¤ SAFETY,BEFORE OPERATING

SN: B29001-UP

1шт.

14

0

PLATE¤ CAUTION,SAFETY COMFIRM OF REAR

SN: B29001-UP

1шт.

15

14X-98-11161

PLATE¤ SAFETY,ADJUSTING TRACK SHOE

SN: B29001-UP

2шт.

16

12G-98-51110

PLATE,OIL CHART

SN: B29001-UP

1шт.

17

124-98-51120

PLATE,PRESSURE TEST (C AND B)

SN: B29001-UP

1шт.

18

09690-C0400

PLATE¤ MARK,KOMATSU¤ REAR

SN: B29001-UP

1шт.

19

124-98-51190

PLATE¤ INSTRUCTION,POWER LINE OIL ELEMENT

SN: B29001-UP

1шт.

20

600-021-1251

PLATE,EXHAUSTED GUS CONTROL

SN: B29001-UP

1шт.

21

09963-00100

TAG,DO NOT OPERATE

SN: B29001-UP

1шт.

22

124-98-51270

PLATE¤ CAUTION,SUPER ANGLE

SN: B29001-UP

1шт.

23

09637-01163

PLATE¤ INSTRUCTION,AIR CLEANER

SN: B29001-UP

1шт.

24

12G-98-51210

PLATE¤ MARK,D41PF

SN: B29001-UP

2шт.

25

12G-98-51130

PLATE¤ SAFETY

SN: B29001-UP

1шт.

26

09602-10050

PLATE¤ NAME,(LIMITED SUPPLY)

SN: B29001-UP

1шт.

|26

04418-13060

SCREW

SN: B29001-UP

4шт.
