Запчасти Komatsu D41P-6K МАРКИРОВКА (ЯПОН.)(№-) МАРКИРОВКА

1

14X-98-11170

PLATE¤ OPERATING,LOCK

SN: 50001-@

2шт.

2

14X-98-11240

PLATE¤ OPERATING,STEERING LEVER (C AND B)

SN: 50001-@

1шт.

3

09690-B0224

PLATE¤ MARK,KOMATSU¤ FRONT

SN: 50001-@

1шт.

4

124-98-51140

PLATE¤ OPERATING,WORK EQUIP.LEVER (PAT DOZER)

SN: 50001-@

1шт.

5

17A-98-11180

PLATE,HORN

SN: 50001-@

1шт.

6

09651-A0640

PLATE¤ SAFETY,BEFORE OPERATING

SN: 50001-50200

1шт.

7

09657-A0880

PLATE¤ SAFETY,ADJUSTING TRACK SHOE

SN: 50001-@

2шт.

8

124-98-51110

OIL CHART

SN: 50001-@

1шт.

9

124-98-51120

PLATE,PRESSURE TEST (C AND B)

SN: 50001-@

1шт.

10

09690-C0400

PLATE¤ MARK,KOMATSU¤ REAR

SN: 50001-50200

1шт.

11

124-98-51190

PLATE¤ INSTRUCTION,POWER LINE OIL ELEMENT

SN: 50001-@

1шт.

12

600-021-1251

PLATE,EXHAUSTED GUS CONTROL

SN: 50001-@

1шт.

13

09963-00100

TAG,DO NOT OPERATE

SN: 50001-50200

1шт.

14

124-98-51270

PLATE¤ CAUTION,SUPER ANGLE (NOT SHOWN)

SN: 50001-@

1шт.

15

09637-01163

PLATE¤ INSTRUCTION,AIR CLEANER (NOT SHOWN)

SN: 50001-@

1шт.

16

09802-10100

PLATE¤ SAFETY,SAFETY COMFIRM OF REAR

SN: 50001-@

1шт.

17

09653-A0480

PLATE¤ SAFETY,OIL TANK AND RADIATOR CAP

SN: 50001-@

2шт.

18

09654-B0640

PLATE¤ SAFETY,BEFORE AND AFTER OPERATION

SN: 50001-50200

1шт.

19

09667-A0480

PLATE¤ SAFETY,FAN BELT

SN: 50001-@

2шт.

20

09806-B1200

PLATE¤ SAFETY,DANGER¤ KEEP AWAY

SN: 50001-@

2шт.

21

09808-A0880

PLATE¤ SAFETY,BATTERY CABLE

SN: 50001-@

1шт.

22

12G-54-45150

PLATE¤ MARK,D41P

SN: 50001-50200

2шт.

23

124-98-51131

PLATE¤ SAFETY

SN: 50001-50200

1шт.

24

09602-10000

PLATE¤ NAME,(LIMITED SUPPLY)

SN: 50001-@

1шт.

|24

04418-13060

SCREW

SN: 50001-@

4шт.
