Запчасти Komatsu D41P-6 МАРКИРОВКА (ПОРТУГАЛ.) МАРКИРОВКА

1

14X-98-11170

PLATE¤ OPERATING,LOCK

SN: B30001-UP

2шт.

2

14X-98-11240

PLATE¤ OPERATING,STEERING LEVER (C AND B)

SN: B30001-UP

1шт.

3

09690-P0400

PLATE¤ MARK,KOMATSU¤ FRONT

SN: B30001-UP

1шт.

4

124-98-51140

PLATE¤ OPERATING,WORK EQUIPMENT LEVER

SN: B30001-UP

1шт.

5

17A-98-11180

PLATE,HORN

SN: B30001-UP

1шт.

6

09690-M0063

PLATE¤ MARK

SN: B30001-UP

1шт.

7

134-54-66190

PLATE,PROTECTION FILM

SN: B30001-UP

2шт.

8

134-54-66290

PLATE,PROTECTION FILM

SN: B30001-UP

2шт.

9

09653-07001

PLATE¤ SAFETY,HYDRAULIC OIL TANK

SN: B30001-UP

1шт.

10

124-98-51920

PLATE¤ CAUTION,SUPER ANGLE

SN: B30001-UP

1шт.

11

09654-37001

PLATE¤ SAFETY,AFTER OPERATING

SN: B30001-UP

1шт.

12

09651-07001

PLATE¤ SAFETY,BEFORE OPERATING

SN: B30001-UP

1шт.

13

09657-07002

PLATE¤ SAFETY,ADJUSTING TRACK SHOE

SN: B30001-UP

2шт.

14

124-98-62110

OIL CHART

SN: B30001-UP

1шт.

15

124-98-51860

PLATE¤ INSTRUCTION,PRESSURE TEST

SN: B30001-UP

1шт.

16

09690-P0800

PLATE¤ MARK,KOMATSU¤ REAR

SN: B30001-UP

1шт.

17

126-98-51190

PLATE¤ INSTRUCTION,POWER LINE OIL ELEMENT

SN: B30001-UP

1шт.

18

09637-50263

PLATE¤ INSTRUCTION,AIR CLEANER

SN: B30001-UP

1шт.

19

09802-17000

PLATE¤ SAFETY,SAFETY COMFIRM OF REAR

SN: B30001-UP

1шт.

20

09668-07001

PLATE¤ SAFETY,RADIATOR

SN: B30001-UP

1шт.

21

09690-P0400

PLATE¤ MARK,KOMATSU

SN: B30001-UP

1шт.

22

09690-P0315

PLATE¤ MARK,KOMATSU

SN: B30001-UP

1шт.

23

09808-07000

PLATE¤ SAFETY,BATTERY CABLE

SN: B30001-UP

1шт.

24

124-98-61611

PLATE¤ MARK,D41P

SN: B30001-UP

1шт.

25

124-98-61651

PLATE¤ MARK

SN: B30001-UP

1шт.

26

124-98-61621

PLATE¤ MARK,D41P

SN: B30001-UP

1шт.

27

09602-10050

PLATE¤ NAME,(LIMITED SUPPLY)

SN: B30001-UP

1шт.

28

04418-13060

SCREW

SN: B30001-UP

4шт.
