Запчасти Komatsu D41P-6 МАРКИРОВКА (АНГЛ.) (REGULATION OF EC INCLUSION) МАРКИРОВКА

1

14X-98-11170

PLATE¤ OPERATING,LOCK

SN: B20001-UP

2шт.

2

14X-98-11240

PLATE¤ OPERATING,STEERING LEVER (C AND B)

SN: B20001-UP

1шт.

3

09690-B0224

PLATE¤ MARK,KOMATSU¤ FRONT

SN: B20001-UP

1шт.

4

124-98-51140

PLATE¤ OPERATING,WORK EQUIP.LEVER (PAT DOZER)

SN: B20001-UP

1шт.

5

17A-98-11180

PLATE,HORN

SN: B20001-UP

1шт.

6

09653-A0540

PLATE¤ SAFETY,OPERATING OIL TANK

SN: B20001-UP

1шт.

|6

09653-30540

PLATE¤ SAFETY,OPERATING OIL TANK

SN: B20001-UP

1шт.

7

09653-A0540

PLATE¤ SAFETY,RADIATOR

SN: B20001-UP

1шт.

|7

09653-30540

PLATE¤ SAFETY,RADIATOR

SN: B20001-UP

1шт.

8

09654-B1450

PLATE¤ SAFETY,BEFORE AND AFTER OPERATION

SN: B20001-UP

1шт.

9

14X-98-11580

PLATE¤ SAFETY,BEFORE OPERATING

SN: B20001-B20001

1шт.

10

09802-B0750

PLATE¤ SAFETY,SAFETY COMFIRM OF REAR

SN: B20001-UP

1шт.

11

09657-A0750

PLATE¤ SAFETY,ADJUSTING TRACK SHOE

SN: B20001-UP

2шт.

12

124-98-52110

PLATE,OIL CHART

SN: B20001-UP

1шт.

13

124-98-51170

PLATE,PRESSURE TEST (C AND B)

SN: B20001-UP

1шт.

14

09690-C0400

PLATE¤ MARK,KOMATSU¤ REAR

SN: B20001-UP

1шт.

15

124-98-51290

PLATE¤ INSTRUCTION,POWER LINE OIL ELEMENT

SN: B20001-UP

1шт.

15A

124-98-52160

PLATE¤ CAUTION,SUPER ANGLE

SN: B20001-UP

1шт.

15B

09637-30163

PLATE¤ INSTRUCTION,AIR CLEANER

SN: B20001-UP

1шт.

16

12G-54-45150

PLATE¤ MARK,D41P

SN: B20001-UP

2шт.

17

09602-00050

PLATE¤ NAME,(LIMITED SUPPLY)

SN: B20001-UP

1шт.

|17

04418-13060

SCREW

SN: B20001-UP

4шт.

18

09806-B1750

PLATE¤ SAFETY,DANGER¤ KEEP AWAY

SN: B20001-UP

2шт.

19

362-54-17320

PLATE¤ OPERATING,FUEL CONTROL LEVER

SN: B20001-UP

1шт.

20

09963-A1640

TAG,DO NOT OPERATE

SN: B20001-UP

1шт.

21

09696-00108

PLATE,AMBIENT NOISE INDICATION

SN: B20001-UP

1шт.

22

09696-10083

PLATE,NOISE INDICATION OF OPE. EARS

SN: B20001-UP

1шт.

23

09667-A0900

PLATE¤ SAFETY,DON'T OPEN COVER

SN: B20001-UP

2шт.
