Запчасти Komatsu 6D105-1DD-P СТАРТЕР (.KW) ЭЛЕКТРИКА

|1

600-813-3280

STARTING MOTOR ASS'Y,(5.5KW)

SN: 92268-UP

1шт.

|$$2

THE NIKKO DENKI PART NUMBER IS THAT KD IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

1

KD7-23100-0220

ARMATURE ASS'Y

SN: 92268-UP

1шт.

2

KD1-0454-60047

BEARING,BALL¤ FRONT

SN: 92268-UP

1шт.

3

KD1-0454-62007

BEARING,BALL¤ REAR

SN: 92268-UP

1шт.

4

KD0-23230-0210

FIELD COIL ASS'Y

SN: 92268-UP

1шт.

5

KD1-23785-0100

LEAD WIRE ASS'Y

SN: 92268-UP

1шт.

6

KD7-23780-0040

TERMINAL ASS'Y

SN: 92268-UP

1шт.

7

KD1-23310-0510

FRONT BRACKET ASS'Y

SN: 92268-UP

1шт.

8

KD7-23351-0140

METAL

SN: 92268-UP

1шт.

9

KD7-23120-0270

SHAFT ASS'Y

SN: 92268-UP

1шт.

10

KD1-0454-60057

BEARING,BALL

SN: 92268-UP

1шт.

11

KD1-23181-0030

STOPPER,PINION

SN: 92268-UP

1шт.

12

KD1-23914-0030

RING

SN: 92268-UP

2шт.

13

KD1-23500-0250

CLUTCH ASS'Y

SN: 92268-UP

1шт.

14

KD1-23600-0160

CENTER BRACKET A.

SN: 92268-UP

1шт.

15

KD1-23611-0430

BRACKET

SN: 92268-UP

1шт.

16

KD7-23320-0040

SHIFT LEVER ASS'Y

SN: 92268-UP

1шт.

17

KD0-47100-3510

MAGNETIC SWITCH A.

SN: 92268-UP

1шт.

|18

KD7-23700-0600

REAR BRACKET ASS'Y

SN: 92268-UP

1шт.

18

KD0-23711-0170

BRACKET,REAR

SN: 92268-UP

1шт.

19

KD1-23913-0010

SPRING,BRUSH

SN: 92268-UP

4шт.

20

KD0-23750-0120

BRUSH HOLDER A.

SN: 92268-UP

1шт.

21

KD1-23740-0170

BRUSH (+)

SN: 92268-UP

2шт.

22

KD0-23740-0180

BRUSH (-)

SN: 92268-UP

2шт.

23

KD1-23901-0080

BOLT

SN: 92268-UP

2шт.

24

KD0-25000-6081

SWITCH ASS'Y

SN: 92268-UP

1шт.

25

KD7-09210-1330

SEAL ASS'Y,(NOT SHOWN)

SN: 92268-UP

1шт.
