Запчасти Komatsu 6D105-1DD-P ТОПЛ. НАСОС (РЕГУЛЯТОР) (/) ТОПЛИВН. СИСТЕМА

|1

6136-72-1481

INJECTION PUMP ASS'Y

SN: 92282-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453¤0454¤ 0463¤ 0464¤ 0472 TO 0482.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105410-9431

GOVERNOR ASS'Y

SN: 92282-UP

1шт.

|$$5

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0463 AND 0464.

-1шт.

1

DK154011-0100

NUT,LOCK

SN: 92282-UP

1шт.

2

DK154500-7520

COVER

SN: 92282-UP

1шт.

3

DK014110-3440

WASHER,SPRING

SN: 92282-UP

1шт.

4

DK026516-2040

GASKET

SN: 92282-UP

1шт.

5

DK154316-6600

ADAPTER

SN: 92282-UP

1шт.

6

DK154031-3000

SCREW

SN: 92282-UP

1шт.

7

DK139206-0600

NUT

SN: 92282-UP

1шт.

8

DK154036-0300

PLUG

SN: 92282-UP

1шт.

9

DK020106-5040

BOLT

SN: 92282-UP

2шт.

10

DK154010-0300

SCREW

SN: 92282-UP

1шт.

11

DK020106-3840

BOLT

SN: 92282-UP

4шт.

12

DK154063-5100

COVER

SN: 92282-UP

1шт.

13

DK029020-6210

BOLT

SN: 92282-UP

2шт.

14

DK020006-1640

BOLT

SN: 92282-UP

2шт.

15

DK154150-2700

SPRING

SN: 92282-UP

1шт.

16

DK154158-0820

CAPSULE,SPRING

SN: 92282-UP

1шт.

17

DK154011-1700

NUT

SN: 92282-UP

1шт.

18

DK026512-1540

GASKET

SN: 92282-UP

2шт.

19

DK154159-1200

NUT,CAP

SN: 92282-UP

1шт.

20

DK154200-7220

LEVER ASS'Y,SWIVEL

SN: 92282-UP

1шт.

21

DK154204-3000

BUSHING

SN: 92282-UP

1шт.

22

DK029631-8020

O-RING

SN: 92282-UP

2шт.

23

DK016010-1640

RING,SNAP

SN: 92282-UP

2шт.

24

DK139611-0000

SEAL,OIL

SN: 92282-UP

1шт.

25

DK139411-0000

SHIM¤ 0.40MM

SN: 92282-UP

1шт.

26

DK029311-1090

SHIM¤ 0.30MM

SN: 92282-UP

-2шт.

27

DK154204-3100

BUSHING

SN: 92282-UP

1шт.

28

DK025803-1310

KEY¤ 13MM

SN: 92282-UP

1шт.

29

DK154206-2800

COLLAR

SN: 92282-UP

1шт.

30

DK154206-0200

WASHER¤ 1.0MM

SN: 92282-UP

-2шт.

31

DK154237-1100

PIN

SN: 92282-UP

1шт.

32

DK154341-7820

LEVER

SN: 92282-UP

1шт.

33

DK154350-7800

GASKET

SN: 92282-UP

1шт.

34

DK029635-2020

O-RING

SN: 92282-UP

1шт.

35

DK029731-2040

BOLT,EYE

SN: 92282-UP

1шт.

36

DK029341-2140

GASKET

SN: 92282-UP

2шт.

37

DK026506-1040

GASKET

SN: 92282-UP

2шт.

38

DK154035-1600

NUT,CAP

SN: 92282-UP

1шт.
