Запчасти Komatsu 6D105-1L ТОПЛ. НАСОС (СОЕДИНЕНИЕ)(№-) ТОПЛИВН. СИСТЕМА

|1

6136-72-1410

INJECTION PUMP ASS'Y

SN: 50001-UP

1шт.

|1

6136-72-1450

INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

|1

6136-72-1460

INJECTION PUMP ASS'Y,(EUROPE SPEC.)

SN: 50001-UP

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105661-0371

COUPLING ASS'Y

SN: 50001-UP

1шт.

1

DK156630-0500

COUPLING

SN: 50001-UP

1шт.

2

DK156605-2320

PLATE

SN: 50001-UP

2шт.

3

DK156609-5900

COUPLING,CROSS

SN: 50001-UP

1шт.

4

DK156633-6200

BOLT

SN: 50001-UP

8шт.

5

DK156615-3300

WASHER,LOCK

SN: 50001-UP

2шт.

6

DK029200-8050

NUT

SN: 50001-UP

2шт.

7

DK156633-6000

BOLT

SN: 50001-UP

1шт.

|1

6136-72-1410

INJECTION PUMP ASS'Y

SN: 50001-UP

1шт.

|1

6136-72-1450

INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

|1

6136-72-1460

INJECTION PUMP ASS'Y,(EUROPE SPEC.)

SN: 50001-UP

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105661-0371

COUPLING ASS'Y

SN: 50001-UP

1шт.

1

DK156630-0500

COUPLING

SN: 50001-UP

1шт.

2

DK156605-2320

PLATE

SN: 50001-UP

2шт.

3

DK156609-5900

COUPLING,CROSS

SN: 50001-UP

1шт.

4

DK156633-6200

BOLT

SN: 50001-UP

8шт.

5

DK156615-3300

WASHER,LOCK

SN: 50001-UP

2шт.

6

DK029200-8050

NUT

SN: 50001-UP

2шт.

7

DK156633-6000

BOLT

SN: 50001-UP

1шт.
