Артикул
Название
Примечание
Количество
|$0
6136-72-1410
INJECTION PUMP ASS'Y
SN: 50001-UP
1шт.
|$1
6136-72-1450
INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
|$2
6136-72-1460
INJECTION PUMP ASS'Y,(EUROPE SPEC.)
SN: 50001-UP
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$5
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$5
DK105661-0371
COUPLING ASS'Y
SN: 50001-UP
1шт.
1
DK156630-0500
COUPLING
SN: 50001-UP
1шт.
2
DK156605-2320
PLATE
SN: 50001-UP
2шт.
3
DK156609-5900
COUPLING,CROSS
SN: 50001-UP
1шт.
4
DK156633-6200
BOLT
SN: 50001-UP
8шт.
5
DK156615-3300
WASHER,LOCK
SN: 50001-UP
2шт.
6
DK029200-8050
NUT
SN: 50001-UP
2шт.
7
DK156633-6000
BOLT
SN: 50001-UP
1шт.
|$0
6136-72-1410
INJECTION PUMP ASS'Y
SN: 50001-UP
1шт.
|$1
6136-72-1450
INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)
SN: 55043-UP
1шт.
|$2
6136-72-1460
INJECTION PUMP ASS'Y,(EUROPE SPEC.)
SN: 50001-UP
1шт.
|$$4
THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$5
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$5
DK105661-0371
COUPLING ASS'Y
SN: 50001-UP
1шт.
1
DK156630-0500
COUPLING
SN: 50001-UP
1шт.
2
DK156605-2320
PLATE
SN: 50001-UP
2шт.
3
DK156609-5900
COUPLING,CROSS
SN: 50001-UP
1шт.
4
DK156633-6200
BOLT
SN: 50001-UP
8шт.
5
DK156615-3300
WASHER,LOCK
SN: 50001-UP
2шт.
6
DK029200-8050
NUT
SN: 50001-UP
2шт.
7
DK156633-6000
BOLT
SN: 50001-UP
1шт.
Выбрано товаров: 26
