Запчасти Komatsu 6D105-1L ТОПЛ. НАСОС (РЕГУЛЯТОР) (/)(№-) ТОПЛИВН. СИСТЕМА

|$0

6136-72-1410

INJECTION PUMP ASS'Y

SN: 50001-UP

1шт.

|$1

6136-72-1450

INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

|$2

6136-72-1460

INJECTION PUMP ASS'Y,(EUROPE SPEC.)

SN: 50001-UP

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451A TO 0481A.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$5

DK105410-6280

GOVERNOR ASS'Y

SN: 50001-UP

1шт.

|$6

DK105410-6380

GOVERNOR ASS'Y,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

|$$8

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.

-1шт.

1

DK154000-6400

HOUSING

SN: 50001-UP

1шт.

2

DK029632-5070

O-RING

SN: 50001-UP

1шт.

3

DK154007-2900

PLUG

SN: 50001-UP

1шт.

4

DK154007-0200

ADAPTER

SN: 50001-UP

1шт.

5

DK020018-1840

BOLT

SN: 50001-UP

1шт.

6

DK154350-1900

PLATE

SN: 50001-UP

1шт.

7

DK020006-1440

BOLT

SN: 50001-UP

6шт.

8

DK154010-0100

SCREW

SN: 50001-UP

1шт.

9

DK154011-0100

NUT,LOCK

SN: 50001-UP

1шт.

10

DK154050-1720

LIMITER

SN: 50001-UP

1шт.

11

DK154100-9720

FLYWEIGHT ASS'Y

SN: 50001-UP

1шт.

12

DK025803-1610

KEY, 16MM

SN: 50001-UP

1шт.

13

DK029321-2020

WASHER,SPRING

SN: 50001-UP

1шт.

14

DK029231-2030

NUT

SN: 50001-UP

1шт.

15

DK154123-0120

SLEEVE

SN: 50001-UP

1шт.

15

DK029801-0030

BEARING

SN: 50001-UP

1шт.

16

DK029311-0010

SHIM, 0.20MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK029311-0180

SHIM, 0.30MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK029311-0190

SHIM, 0.40MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-0000

SHIM, 0.50MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK029311-0210

SHIM, 1.00MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-0100

SHIM, 1.50MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-3000

SHIM, 2.00MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-3100

SHIM, 3.00MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-3200

SHIM, 4.00MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

17

DK154154-0701

SPRING

SN: 50001-UP

1шт.

18

DK154175-4620

CAPSULE,SPRING

SN: 50001-UP

1шт.

18

DK154185-2220

CAPSULE,SPRING (HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

19

DK029201-6080

NUT

SN: 50001-UP

1шт.

20

DK154211-3820

GUIDE LEVER ASS'Y

SN: 50001-UP

1шт.

21

DK154230-0120

LINK

SN: 50001-UP

1шт.

22

DK016010-0540

RING,SNAP

SN: 50001-UP

1шт.

23

DK154236-1500

LEVER,TENSION

SN: 50001-UP

1шт.

24

DK155412-5200

IMPELLER

SN: 50001-UP

1шт.

25

DK154350-7700

GASKET

SN: 50001-UP

1шт.

26

DK154179-4020

CAPSULE

SN: 50001-UP

1шт.

26

DK154179-0620

CAPSULE,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

27

DK029201-6010

NUT

SN: 50001-UP

1шт.

|$0

6136-72-1410

INJECTION PUMP ASS'Y

SN: 50001-UP

1шт.

|$1

6136-72-1450

INJECTION PUMP ASS'Y,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

|$2

6136-72-1460

INJECTION PUMP ASS'Y,(EUROPE SPEC.)

SN: 50001-UP

1шт.

|$$4

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0451A TO 0481A.

-1шт.

|$$5

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$5

DK105410-6280

GOVERNOR ASS'Y

SN: 50001-UP

1шт.

|$6

DK105410-6380

GOVERNOR ASS'Y,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

|$$8

THESE ASSEMBLIES CONSIST OF ALL PARTS SHOWN IN FIGS.0461A AND 0462A.

-1шт.

1

DK154000-6400

HOUSING

SN: 50001-UP

1шт.

2

DK029632-5070

O-RING

SN: 50001-UP

1шт.

3

DK154007-2900

PLUG

SN: 50001-UP

1шт.

4

DK154007-0200

ADAPTER

SN: 50001-UP

1шт.

5

DK020018-1840

BOLT

SN: 50001-UP

1шт.

6

DK154350-1900

PLATE

SN: 50001-UP

1шт.

7

DK020006-1440

BOLT

SN: 50001-UP

6шт.

8

DK154010-0100

SCREW

SN: 50001-UP

1шт.

9

DK154011-0100

NUT,LOCK

SN: 50001-UP

1шт.

10

DK154050-1720

LIMITER

SN: 50001-UP

1шт.

11

DK154100-9720

FLYWEIGHT ASS'Y

SN: 50001-UP

1шт.

12

DK025803-1610

KEY, 16MM

SN: 50001-UP

1шт.

13

DK029321-2020

WASHER,SPRING

SN: 50001-UP

1шт.

14

DK029231-2030

NUT

SN: 50001-UP

1шт.

15

DK154123-0120

SLEEVE

SN: 50001-UP

1шт.

15

DK029801-0030

BEARING

SN: 50001-UP

1шт.

16

DK029311-0010

SHIM, 0.20MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK029311-0180

SHIM, 0.30MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK029311-0190

SHIM, 0.40MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-0000

SHIM, 0.50MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK029311-0210

SHIM, 1.00MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-0100

SHIM, 1.50MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-3000

SHIM, 2.00MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-3100

SHIM, 3.00MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

16

DK139410-3200

SHIM, 4.00MM,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

-2шт.

17

DK154154-0701

SPRING

SN: 50001-UP

1шт.

18

DK154175-4620

CAPSULE,SPRING

SN: 50001-UP

1шт.

18

DK154185-2220

CAPSULE,SPRING (HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

19

DK029201-6080

NUT

SN: 50001-UP

1шт.

20

DK154211-3820

GUIDE LEVER ASS'Y

SN: 50001-UP

1шт.

21

DK154230-0120

LINK

SN: 50001-UP

1шт.

22

DK016010-0540

RING,SNAP

SN: 50001-UP

1шт.

23

DK154236-1500

LEVER,TENSION

SN: 50001-UP

1шт.

24

DK155412-5200

IMPELLER

SN: 50001-UP

1шт.

25

DK154350-7700

GASKET

SN: 50001-UP

1шт.

26

DK154179-4020

CAPSULE

SN: 50001-UP

1шт.

26

DK154179-0620

CAPSULE,(HIGH ALTITUDE SPEC.)

SN: 55043-UP

1шт.

27

DK029201-6010

NUT

SN: 50001-UP

1шт.
