Запчасти Komatsu D41A-6 МАРКИРОВКА (ПОРТУГАЛ.) МАРКИРОВКА

1

14X-98-11170

PLATE¤ OPERATING,LOCK

SN: B20001-UP

2шт.

2

14X-98-11240

PLATE¤ OPERATING,STEERING LEVER (C AND B)

SN: B20001-UP

1шт.

3

09690-B0224

PLATE¤ MARK,KOMATSU¤ FRONT

SN: B20001-UP

1шт.

4

09690-C0630

PLATE¤ MARK,KOMATSU¤ REAR

SN: B20001-UP

1шт.

5

14X-98-11260

PLATE¤ OPERATING

SN: B20001-UP

1шт.

6

124-54-45160

PLATE¤ MARK,D41A

SN: B20001-UP

2шт.

7

17A-98-11180

PLATE,HORN

SN: B20001-UP

1шт.

8

126-98-51131

PLATE,OIL CHART

SN: B20001-UP

1шт.

9

126-98-51141

PLATE¤ CAUTION,OPERATING OIL TANK

SN: B20001-UP

1шт.

10

126-98-51151

PLATE¤ SAFETY,RADIATOR

SN: B20001-UP

1шт.

11

126-98-51161

PLATE¤ CAUTION,BEFORE AND AFTER OPERATION

SN: B20001-UP

1шт.

12

126-98-51171

PLATE¤ SAFETY,ADJUSTING TRACK SHOE

SN: B20001-UP

2шт.

13

09602-10050

PLATE¤ NAME,(LIMITED SUPPLY)

SN: B20001-UP

1шт.

|13

04418-13060

SCREW

SN: B20001-UP

4шт.

14

126-98-51190

PLATE¤ INSTRUCTION,POWER LINE OIL ELEMENT

SN: B20001-UP

1шт.

15

09637-50263

PLATE¤ INSTRUCTION,AIR CLEANER

SN: B20001-UP

1шт.
