Запчасти Komatsu 6D105-1DD-A ТОПЛ. НАСОС (СОЕДИНЕНИЕ) ТОПЛИВН. СИСТЕМА

|1

6136-72-1481

INJECTION PUMP ASS'Y

SN: 92282-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453¤0454¤ 0463¤ 0464¤ 0472 TO 0482.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105661-0371

COUPLING ASS'Y

SN: 92282-UP

1шт.

1

DK156630-0500

COUPLING

SN: 92282-UP

1шт.

2

DK156605-2320

PLATE

SN: 92282-UP

2шт.

3

DK156609-5900

COUPLING,CROSS

SN: 92282-UP

1шт.

4

DK156633-6200

BOLT

SN: 92282-UP

8шт.

5

DK156615-3300

WASHER

SN: 92282-UP

2шт.

6

DK029200-8050

NUT

SN: 92282-UP

2шт.

7

DK156633-6000

BOLT

SN: 92282-UP

1шт.

|1

6136-72-1481

INJECTION PUMP ASS'Y

SN: 92282-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453¤0454¤ 0463¤ 0464¤ 0472 TO 0482.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105661-0371

COUPLING ASS'Y

SN: 92282-UP

1шт.

1

DK156630-0500

COUPLING

SN: 92282-UP

1шт.

2

DK156605-2320

PLATE

SN: 92282-UP

2шт.

3

DK156609-5900

COUPLING,CROSS

SN: 92282-UP

1шт.

4

DK156633-6200

BOLT

SN: 92282-UP

8шт.

5

DK156615-3300

WASHER

SN: 92282-UP

2шт.

6

DK029200-8050

NUT

SN: 92282-UP

2шт.

7

DK156633-6000

BOLT

SN: 92282-UP

1шт.
