Артикул
Название
Примечание
Количество
|$0
6136-72-1440
INJECTION PUMP ASS'Y
SN: 55043-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0459 TO 0486.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK101060-2470
PUMP ASS'Y
SN: 55043-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0459 AND 0460.
-1шт.
1
DK131034-1401
PLUG
SN: 55043-UP
6шт.
2
DK131151-5820
PLUNGER ASS'Y
SN: 55043-UP
6шт.
3
DK131110-7720
VALVE,DELIVERY
SN: 55043-UP
6шт.
4
DK131112-1600
SPRING
SN: 55043-UP
6шт.
6
DK131116-7600
HOLDER
SN: 55043-UP
6шт.
7
DK131117-2300
STOPPER
SN: 55043-UP
6шт.
8
DK131122-0520
PLATE ASS'Y
SN: 55043-UP
3шт.
10
DK131200-0620
TAPPET ASS'Y
SN: 55043-UP
6шт.
11
DK131201-0100
NUT
SN: 55043-UP
1шт.
12
DK131202-0100
BOLT,TAPPET
SN: 55043-UP
1шт.
13
DK131203-0200
PIN
SN: 55043-UP
1шт.
14
DK131204-1000
ROLLER
SN: 55043-UP
1шт.
15
DK131205-0500
BUSHING
SN: 55043-UP
1шт.
16
DK131206-0200
GUIDE
SN: 55043-UP
1шт.
17
DK131215-2400
SPRING,PLUNGER
SN: 55043-UP
6шт.
18
DK131216-0100
SEAT,SPRING
SN: 55043-UP
6шт.
19
DK131217-0100
SEAT,SPRING
SN: 55043-UP
6шт.
21
DK131226-0300
SCREW
SN: 55043-UP
1шт.
22
DK131240-0100
PINION
SN: 55043-UP
6шт.
23
DK131241-0100
SLEEVE,CONTROL
SN: 55043-UP
6шт.
24
DK131242-0100
SCREW
SN: 55043-UP
6шт.
|$0
6136-72-1440
INJECTION PUMP ASS'Y
SN: 55043-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0459 TO 0486.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK101060-2470
PUMP ASS'Y
SN: 55043-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0459 AND 0460.
-1шт.
1
DK131034-1401
PLUG
SN: 55043-UP
6шт.
2
DK131151-5820
PLUNGER ASS'Y
SN: 55043-UP
6шт.
3
DK131110-7720
VALVE,DELIVERY
SN: 55043-UP
6шт.
4
DK131112-1600
SPRING
SN: 55043-UP
6шт.
6
DK131116-7600
HOLDER
SN: 55043-UP
6шт.
7
DK131117-2300
STOPPER
SN: 55043-UP
6шт.
8
DK131122-0520
PLATE ASS'Y
SN: 55043-UP
3шт.
10
DK131200-0620
TAPPET ASS'Y
SN: 55043-UP
6шт.
11
DK131201-0100
NUT
SN: 55043-UP
1шт.
12
DK131202-0100
BOLT,TAPPET
SN: 55043-UP
1шт.
13
DK131203-0200
PIN
SN: 55043-UP
1шт.
14
DK131204-1000
ROLLER
SN: 55043-UP
1шт.
15
DK131205-0500
BUSHING
SN: 55043-UP
1шт.
16
DK131206-0200
GUIDE
SN: 55043-UP
1шт.
17
DK131215-2400
SPRING,PLUNGER
SN: 55043-UP
6шт.
18
DK131216-0100
SEAT,SPRING
SN: 55043-UP
6шт.
19
DK131217-0100
SEAT,SPRING
SN: 55043-UP
6шт.
21
DK131226-0300
SCREW
SN: 55043-UP
1шт.
22
DK131240-0100
PINION
SN: 55043-UP
6шт.
23
DK131241-0100
SLEEVE,CONTROL
SN: 55043-UP
6шт.
24
DK131242-0100
SCREW
SN: 55043-UP
6шт.
Выбрано товаров: 58
