Артикул
Название
Примечание
Количество
|1
6136-72-1491
INJECTION PUMP ASS'Y
SN: 92268-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105661-0371
COUPLING ASS'Y
SN: 92268-UP
1шт.
1
DK156630-0500
COUPLING
SN: 92268-UP
1шт.
2
DK156605-2320
PLATE
SN: 92268-UP
2шт.
3
DK156609-5900
COUPLING,CROSS
SN: 92268-UP
1шт.
4
DK156633-6200
BOLT
SN: 92268-UP
8шт.
5
DK156615-3300
WASHER
SN: 92268-UP
2шт.
6
DK029200-8050
NUT
SN: 92268-UP
2шт.
7
DK156633-6000
BOLT
SN: 92268-UP
1шт.
|1
6136-72-1491
INJECTION PUMP ASS'Y
SN: 92268-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105661-0371
COUPLING ASS'Y
SN: 92268-UP
1шт.
1
DK156630-0500
COUPLING
SN: 92268-UP
1шт.
2
DK156605-2320
PLATE
SN: 92268-UP
2шт.
3
DK156609-5900
COUPLING,CROSS
SN: 92268-UP
1шт.
4
DK156633-6200
BOLT
SN: 92268-UP
8шт.
5
DK156615-3300
WASHER
SN: 92268-UP
2шт.
6
DK029200-8050
NUT
SN: 92268-UP
2шт.
7
DK156633-6000
BOLT
SN: 92268-UP
1шт.
Выбрано товаров: 22
