Артикул
Название
Примечание
Количество
|$0
6136-71-1430
INJECTION PUMP ASS'Y
SN: 16269-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 TO 0485.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105210-1840
FEED PUMP ASS'Y
SN: 16269-UP
1шт.
1
DK152000-3620
HOUSING
SN: 16269-UP
1шт.
2
DK152100-1120
PISTON
SN: 16269-UP
1шт.
3
DK152102-0400
SPRING,PISTON
SN: 16269-UP
1шт.
4
DK152105-0200
PLUG
SN: 16269-UP
1шт.
6
DK152111-2820
TAPPET ASS'Y
SN: 16269-UP
1шт.
7
DK152112-0100
ROLLER
SN: 16269-UP
1шт.
8
DK152113-0700
PIN
SN: 16269-UP
1шт.
9
DK152114-0400
GUIDE
SN: 16269-UP
2шт.
10
DK152121-0200
RING,SNAP
SN: 16269-UP
1шт.
13
DK152117-0100
PLUG
SN: 16269-UP
1шт.
17
DK152300-0920
BOLT,JOINT
SN: 16269-UP
1шт.
|$0
6136-71-1430
INJECTION PUMP ASS'Y
SN: 16269-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 TO 0485.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|$3
DK105210-1840
FEED PUMP ASS'Y
SN: 16269-UP
1шт.
1
DK152000-3620
HOUSING
SN: 16269-UP
1шт.
2
DK152100-1120
PISTON
SN: 16269-UP
1шт.
3
DK152102-0400
SPRING,PISTON
SN: 16269-UP
1шт.
4
DK152105-0200
PLUG
SN: 16269-UP
1шт.
6
DK152111-2820
TAPPET ASS'Y
SN: 16269-UP
1шт.
7
DK152112-0100
ROLLER
SN: 16269-UP
1шт.
8
DK152113-0700
PIN
SN: 16269-UP
1шт.
9
DK152114-0400
GUIDE
SN: 16269-UP
2шт.
10
DK152121-0200
RING,SNAP
SN: 16269-UP
1шт.
13
DK152117-0100
PLUG
SN: 16269-UP
1шт.
17
DK152300-0920
BOLT,JOINT
SN: 16269-UP
1шт.
Выбрано товаров: 46
