Артикул
Название
Примечание
Количество
|1
6136-72-1690
INJECTION PUMP ASS'Y
SN: 92268-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 TO 0485.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105410-9750
GOVERNOR ASS'Y
SN: 92268-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0465 AND 0466.
-1шт.
1
DK154500-7520
COVER
SN: 92268-UP
1шт.
2
DK014110-3440
WASHER,SPRING
SN: 92268-UP
1шт.
3
DK026516-2040
GASKET
SN: 92268-UP
1шт.
4
DK154316-6600
ADAPTER
SN: 92268-UP
1шт.
6
DK154031-3000
SCREW
SN: 92268-UP
1шт.
7
DK029240-6010
NUT
SN: 92268-UP
1шт.
8
DK154036-0300
PLUG
SN: 92268-UP
1шт.
9
DK020106-5040
BOLT
SN: 92268-UP
2шт.
10
DK154010-0300
SCREW
SN: 92268-UP
1шт.
11
DK020106-3840
BOLT
SN: 92268-UP
4шт.
12
DK154063-5100
COVER
SN: 92268-UP
1шт.
13
DK029020-6210
BOLT
SN: 92268-UP
2шт.
14
DK020006-1640
BOLT
SN: 92268-UP
2шт.
16
DK154158-0820
CAPSULE,SPRING
SN: 92268-UP
1шт.
17
DK154011-1700
NUT
SN: 92268-UP
1шт.
20
DK154200-3120
LEVER,SWIVEL
SN: 92268-UP
1шт.
21
DK154204-1900
BUSHING
SN: 92268-UP
2шт.
23
DK016010-1640
RING,SNAP
SN: 92268-UP
2шт.
27
DK029141-7010
PLUG
SN: 92268-UP
1шт.
32
DK154341-7820
LEVER
SN: 92268-UP
1шт.
35
DK029731-2040
BOLT,EYE
SN: 92268-UP
1шт.
|1
6136-72-1690
INJECTION PUMP ASS'Y
SN: 92268-UP
1шт.
|$$2
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0455 TO 0485.
-1шт.
|$$3
THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.
-1шт.
|1
DK105410-9750
GOVERNOR ASS'Y
SN: 92268-UP
1шт.
|$$5
THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0465 AND 0466.
-1шт.
1
DK154500-7520
COVER
SN: 92268-UP
1шт.
2
DK014110-3440
WASHER,SPRING
SN: 92268-UP
1шт.
3
DK026516-2040
GASKET
SN: 92268-UP
1шт.
4
DK154316-6600
ADAPTER
SN: 92268-UP
1шт.
6
DK154031-3000
SCREW
SN: 92268-UP
1шт.
7
DK029240-6010
NUT
SN: 92268-UP
1шт.
8
DK154036-0300
PLUG
SN: 92268-UP
1шт.
9
DK020106-5040
BOLT
SN: 92268-UP
2шт.
10
DK154010-0300
SCREW
SN: 92268-UP
1шт.
11
DK020106-3840
BOLT
SN: 92268-UP
4шт.
12
DK154063-5100
COVER
SN: 92268-UP
1шт.
13
DK029020-6210
BOLT
SN: 92268-UP
2шт.
14
DK020006-1640
BOLT
SN: 92268-UP
2шт.
16
DK154158-0820
CAPSULE,SPRING
SN: 92268-UP
1шт.
17
DK154011-1700
NUT
SN: 92268-UP
1шт.
20
DK154200-3120
LEVER,SWIVEL
SN: 92268-UP
1шт.
21
DK154204-1900
BUSHING
SN: 92268-UP
2шт.
23
DK016010-1640
RING,SNAP
SN: 92268-UP
2шт.
27
DK029141-7010
PLUG
SN: 92268-UP
1шт.
32
DK154341-7820
LEVER
SN: 92268-UP
1шт.
35
DK029731-2040
BOLT,EYE
SN: 92268-UP
1шт.
Выбрано товаров: 86
