Запчасти Komatsu 6D105-1M-AM ТОПЛ. НАСОС (СОЕДИНЕНИЕ)(№9-9999) ТОПЛИВН. СИСТЕМА

|$0

6136-71-1420

INJECTION PUMP ASS'Y

SN: 16269-49999

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0453,0454, 0463, 0464, 0472 TO 0482.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|$3

DK105661-0330

COUPLING ASS'Y

SN: 16269-49999

1шт.

1

DK156630-0500

COUPLING

SN: 16269-49999

1шт.

2

DK156605-1120

PLATE

SN: 16269-49999

2шт.

3

DK156609-2500

COUPLING,CROSS

SN: 16269-49999

1шт.

4

DK156603-4400

BOLT

SN: 16269-49999

2шт.

5

DK156615-0700

WASHER,LOCK

SN: 16269-49999

2шт.

6

DK029200-8050

NUT

SN: 16269-49999

2шт.

7

DK014110-8440

WASHER,SPRING

SN: 16269-49999

2шт.

8

DK156603-9700

BOLT

SN: 16269-49999

6шт.

9

DK014110-8440

WASHER,SPRING

SN: 16269-49999

6шт.

10

DK156622-1100

BUSHING

SN: 16269-49999

4шт.

11

DK156603-7900

BOLT

SN: 16269-49999

1шт.

12

DK029320-8040

WASHER,SPRING

SN: 16269-49999

1шт.
