Запчасти Komatsu 6D105-1CC-A ТОПЛ. НАСОС (ПОДКАЧИВАЮЩ. НАСОС) ТОПЛИВН. СИСТЕМА

|1

6136-72-1491

INJECTION PUMP ASS'Y

SN: 92268-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105230-1080

FEED PUMP ASS'Y

SN: 92268-UP

1шт.

1

DK152050-0420

HOUSING

SN: 92268-UP

1шт.

2

DK152100-1120

PISTON

SN: 92268-UP

1шт.

3

DK152102-0400

SPRING,PISTON

SN: 92268-UP

1шт.

4

DK152105-1500

PLUG

SN: 92268-UP

1шт.

5

DK029332-6030

GASKET

SN: 92268-UP

1шт.

6

DK152111-2820

TAPPET ASS'Y

SN: 92268-UP

1шт.

7

DK152112-0100

ROLLER

SN: 92268-UP

1шт.

8

DK152113-0700

PIN

SN: 92268-UP

1шт.

9

DK152114-0400

GUIDE

SN: 92268-UP

2шт.

10

DK152115-0200

VALVE

SN: 92268-UP

4шт.

11

DK152116-0200

SPRING

SN: 92268-UP

4шт.

12

DK152117-0400

PLUG

SN: 92268-UP

2шт.

13

DK152118-0900

ADAPTER

SN: 92268-UP

1шт.

14

DK029331-6030

GASKET

SN: 92268-UP

2шт.

15

DK029631-6060

O-RING

SN: 92268-UP

2шт.

16

DK152121-0200

RING,SNAP

SN: 92268-UP

1шт.

17

DK152200-5420

PUMP,PRIMING

SN: 92268-UP

1шт.

18

DK152300-5920

BOLT,EYE

SN: 92268-UP

1шт.

19

DK029111-4050

PLUG

SN: 92268-UP

1шт.

20

DK029341-4130

GASKET

SN: 92268-UP

2шт.

21

DK026514-1840

GASKET

SN: 92268-UP

1шт.

22

DK152320-0100

COVER

SN: 92268-UP

1шт.

23

DK029731-4680

BOLT,EYE

SN: 92268-UP

1шт.

24

DK029341-4130

GASKET

SN: 92268-UP

2шт.

|1

6136-72-1491

INJECTION PUMP ASS'Y

SN: 92268-UP

1шт.

|$$2

THIS ASSEMBLY CONSISTS OF ALL PARTS SHOWN IN FIGS.0451 TO 0481.

-1шт.

|$$3

THE ZEXEL PART NUMBER IS THAT DK IS REMOVED FROM KOMATSU PART NUMBER LISTED BELOW.

-1шт.

|1

DK105230-1080

FEED PUMP ASS'Y

SN: 92268-UP

1шт.

1

DK152050-0420

HOUSING

SN: 92268-UP

1шт.

2

DK152100-1120

PISTON

SN: 92268-UP

1шт.

3

DK152102-0400

SPRING,PISTON

SN: 92268-UP

1шт.

4

DK152105-1500

PLUG

SN: 92268-UP

1шт.

5

DK029332-6030

GASKET

SN: 92268-UP

1шт.

6

DK152111-2820

TAPPET ASS'Y

SN: 92268-UP

1шт.

7

DK152112-0100

ROLLER

SN: 92268-UP

1шт.

8

DK152113-0700

PIN

SN: 92268-UP

1шт.

9

DK152114-0400

GUIDE

SN: 92268-UP

2шт.

10

DK152115-0200

VALVE

SN: 92268-UP

4шт.

11

DK152116-0200

SPRING

SN: 92268-UP

4шт.

12

DK152117-0400

PLUG

SN: 92268-UP

2шт.

13

DK152118-0900

ADAPTER

SN: 92268-UP

1шт.

14

DK029331-6030

GASKET

SN: 92268-UP

2шт.

15

DK029631-6060

O-RING

SN: 92268-UP

2шт.

16

DK152121-0200

RING,SNAP

SN: 92268-UP

1шт.

17

DK152200-5420

PUMP,PRIMING

SN: 92268-UP

1шт.

18

DK152300-5920

BOLT,EYE

SN: 92268-UP

1шт.

19

DK029111-4050

PLUG

SN: 92268-UP

1шт.

20

DK029341-4130

GASKET

SN: 92268-UP

2шт.

21

DK026514-1840

GASKET

SN: 92268-UP

1шт.

22

DK152320-0100

COVER

SN: 92268-UP

1шт.

23

DK029731-4680

BOLT,EYE

SN: 92268-UP

1шт.

24

DK029341-4130

GASKET

SN: 92268-UP

2шт.
