Запчасти Komatsu D39E-1A FIG. F-A ПРИВОД TRAIN ТРУБЫ - РАМА - ФИЛЬТР - НАСОС - ФИЛЬТР. СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

1

709 475 C1

TUBE, RMF SUCTION

SN: P096338-UP

1шт.

|$1

343 909 R1

RING, SEAL

SN: P096338-UP

1шт.

2

877 949 C2

FLANGE, SPLIT

SN: P096338-UP

2шт.

|$3

24 621 R1

BOLT, HEX - 3/8NCx2-1/4

SN: P096338-UP

4шт.

3

1312 748 H91

HOSE, TUBE TO STRAINER

SN: P096338-UP

1шт.

|$5

343 906 R1

RING, SEAL - AT TUBE

SN: P096338-UP

1шт.

4

1312 757 H91

HOUSING, SUCTION STRAINER.

SN: P096338-UP

1шт.

|$7

307 915 R1

RING, SEAL STRAINER INLET

SN: P096338-UP

1шт.

5

1269 422 H1

STRAINER, SUCTION

SN: P096338-UP

1шт.

|$9

307 916 R1

RING, SEAL STRAINER OUTLET

SN: P096338-UP

1шт.

6

1312 753 H91

BRACKET

SN: P096338-UP

1шт.

|$11

24 861 R1

BOLT - 1/2NCx1-1/4

SN: P096338-UP

2шт.

|$12

25 536 R1

WASHER - 1/2

SN: P096338-UP

2шт.

7

1312 760 H1

INSULATOR

SN: P096338-UP

1шт.

8

1312 761 H1

CLIP, CONNECTION

SN: P096338-UP

1шт.

|$15

24 840 R1

BOLT - 3/8NCx1

SN: P096338-UP

2шт.

|$16

25 534 R1

WASHER - 3/8

SN: P096338-UP

2шт.

9

9410 208

CONNECTOR, STRAINER

SN: P096338-UP

1шт.

|$18

307 915 R1

RING, SEAL CONNECTOR

SN: P096338-UP

1шт.

10

1312 751 H91

TUBE, PUMP INLET

SN: P096338-UP

1шт.

11

606 447 C91

HOSE, PUMP INLET

SN: P096338-UP

1шт.

12

875 685 C1

CONNECTOR, PUMP INLET

SN: P096338-UP

1шт.

|$22

296 247 R1

RING, SEAL PUMP INLET

SN: P096338-UP

1шт.

13

9410 231

CONNECTOR

SN: P096338-UP

1шт.

|$24

368 269 R1

RING, SEAL

SN: P096338-UP

1шт.

14

1280 340 H1

HOSE, PUMP TO FILTER

SN: P096338-UP

1шт.

15

150 776 C91

ELBOW, 90 DEG INLET

SN: P096338-UP

2шт.

|$27

296 247 R1

RING, SEAL

SN: P096338-UP

2шт.

16

1201 625 C1

HOSE, FILTER TO TEE

SN: P096338-UP

1шт.

|$29

317 262 R1

CLAMP, HOSE

SN: P096338-UP

1шт.

17

9410 335

TEE, AT VALVE

SN: P096338-UP

1шт.

18

PUMP (SEE FIG. F2300-07A0)

SN: P096338-UP

1шт.

19

FILTER, PRESSURE (SEE FIG. F2300-06A0)

SN: P096338-UP

1шт.

|$33

140 483 H1

BOLT, HEX - 3/8NCx1-1/4

SN: P096338-UP

2шт.

|$34

178 372 R1

WASHER, FLAT - 27/64

SN: P096338-UP

4шт.

20

625 875 C1

MOUNT, SHOCK

SN: P096338-UP

2шт.

21

ELBOW, REGULATOR 90 DEG (M PORT) (SEE FIG. F2320-51A0)

SN: P096338-UP

1шт.

22

HOSE (REG M PORT TO NEUTRAL VALVE) (SEE FIG. F2300-04A6)

SN: P096338-UP

1шт.

|$38

306 132 C2

STRAP, TIE

SN: P096338-UP

-2шт.
