Запчасти Komatsu D39E-1A FIG. F-A РУЛЕВ. УПРАВЛЕНИЕ ПРИВОД СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

|$0

1270 564 H91

STEERING DRIVE

SN: P096338-UP

1шт.

1

716 938 C1

CARRIER, PLANET GEAR

SN: P096338-UP

2шт.

2

194 298 R1

RING, RETAINING

SN: P096338-UP

2шт.

3

629 839 C1

GEAR, PLANET

SN: P096338-UP

6шт.

4

629 836 C91

KIT, NEEDLE BEARING

SN: P096338-UP

-2шт.

|$5

NSS

NEEDLE, BEARING

SN: P096338-UP

20шт.

5

629 838 C1

SPACER, NEEDLE BEARING

SN: P096338-UP

6шт.

6

716 939 C1

SHAFT, PLANET GEAR

SN: P096338-UP

6шт.

|$8

19 955 R1

PIN, SPRING - 1/4x1/2

SN: P096338-UP

6шт.

7

659 543 C1

WASHER, THRUST

SN: P096338-UP

12шт.

8

1270 440 H92

GEAR SET, RING AND PINION

SN: P096338-UP

1шт.

|$11

24 998 R1

BOLT, HEX 3/4NFx4 PINION GEAR

SN: P096338-UP

1шт.

|$12

25 796 R1

BOLT, HEX 1-16-20X1 GR8PHC -RING GEAR

SN: P096338-UP

12шт.

|$13

25 535 R1

WASHER, TYPE A PHC HDN

SN: P096338-UP

12шт.

9

622 260 C1

PLATE, RETAINER

SN: P096338-UP

1шт.

10

621 059 C1

CARRIER, RING GEAR

SN: P096338-UP

1шт.

11

372 181 R91

BEARING, TAPERED ROLLER

SN: P096338-UP

2шт.

|$17

372 182 R91

CONE, BEARING

SN: P096338-UP

1шт.

|$18

92 575 H

CUP, BEARING

SN: P096338-UP

1шт.

|$20

OR

-1шт.

|$22

372 183 R91

BEARING, TAPERED ROLLER

SN: P096338-UP

2шт.

|$23

372 184 R91

CONE, BEARING

SN: P096338-UP

1шт.

|$24

74 420 R1

CUP, BEARING

SN: P096338-UP

1шт.

|$26

OR

-1шт.

|$28

621 063 C91

BEARING, TAPERED ROLLER

SN: P096338-UP

2шт.

|$29

622 200 C91

CONE, BEARING

SN: P096338-UP

1шт.

|$30

622 201 C1

CUP, BEARING

SN: P096338-UP

1шт.

|$31

621 064 C91

CARRIER ASSEMBLY, BEARING

SN: P096338-UP

1шт.

12

NSS

CARRIER, BEARING

SN: P096338-UP

1шт.

13

621 066 C1

BUSHING, CARRIER

SN: P096338-UP

2шт.

|$34

26 974 R1

BOLT, HEX 7/16NCx11/2

SN: P096338-UP

12шт.

|$35

25 545 R1

WASHER, FLAT 7/16

SN: P096338-UP

12шт.

14

621 076 C1

SHIM, CARRIER 0.005IN

SN: P096338-UP

-2шт.

|$37

621 077 C1

SHIM, CARRIER 0.007IN

SN: P096338-UP

-2шт.

|$38

621 078 C1

SHIM, CARRIER 0.020IN

SN: P096338-UP

-2шт.

15

621 068 C2

GEAR, SUN

SN: P096338-UP

2шт.

16

621 069 C1

RING, RETAINING

SN: P096338-UP

4шт.

17

621 070 C92

DISC ASSEMBLY, CLUTCH

SN: P096338-UP

2шт.

|$42

621 071 C2

DISC, STEERING HUB

SN: P096338-UP

1шт.

|$43

621 072 C1

HUB, DISC

SN: P096338-UP

2шт.

|$44

23 394 R1

RIVET 1/4x13/8

SN: P096338-UP

4шт.

18

621 073 C93

DISC ASSEMBLY, BRAKE

SN: P096338-UP

2шт.

|$46

621 074 C3

DISC, STEERING BRAKE

SN: P096338-UP

1шт.

|$47

621 075 C2

HUB, DISC

SN: P096338-UP

1шт.

|$48

140 483 H

BOLT, HEX 3/8NCx11/4

SN: P096338-UP

12шт.

|$49

25 534 R1

WASHER, FLAT 3/8

SN: P096338-UP

24шт.

|$50

9413 979

NUT, LOCK 3/8NC

SN: P096338-UP

12шт.

|$51

-1шт.

|$52

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$53

-1шт.

|$54

-1шт.

|$55

F2 - BEFORE SERIAL NUMBER 96482, PART NUMBER WAS 1270 440 H91.

-1шт.

|$56

-1шт.

|$57

-1шт.

|$58

F3 - BEFORE SERIAL NUMBER 96482, PART WAS 734 204 C1 BOLT, HEX 7/16NFX7/8 - RING GEAR.

-1шт.

|$59

-1шт.

|$60

-1шт.

|$61

F4 - WASHER ADDED ON SERIAL NUMBER 96482 AND UP.

-1шт.

|$62

-1шт.
