Запчасти Komatsu D39E-1A FIG. F-A ПРИВОД ЛИНИЯ СИЛОВАЯ ПЕРЕДАЧА И КОНЕЧНАЯ ПЕРЕДАЧА

1

TORQUE CONVERTER (SEE FIG. F2310-51A0)

SN: P096338-UP

1шт.

|$1

30 024 R1

BOLT, HEX M10x45

SN: P096338-UP

12шт.

|$3

OR

-1шт.

|$5

TORQUE CONVERTER (SEE FIG. F2310-52A0)

SN: P096338-UP

1шт.

|$6

931 427 R1

BOLT, HEX M10x40

SN: P096338-UP

12шт.

|$7

30 176 R1

WASHER, FLAT M10

SN: P096338-UP

12шт.

|$8

26 318 R1

BOLT, HEX 1/2NCx11/2FLEX PLATE

SN: P096338-UP

8шт.

|$9

25 536 R1

WASHER, FLAT 1/2FLEX PLATE

SN: P096338-UP

8шт.

2

PUMP, CHARGE AND SCAVENGE (SEE FIG. F2300-07A0)

SN: P096338-UP

1шт.

|$11

468 339 R1

SEAL, MOUNTING

SN: P096338-UP

1шт.

|$12

25 506 R1

BOLT, HEX 1/2NCx15/8

SN: P096338-UP

2шт.

|$13

25 536 R1

WASHER, FLAT 1/2

SN: P096338-UP

2шт.

3

DRIVE SHAFT (SEE FIG. F2200-01A0)

SN: P096338-UP

1шт.

|$15

27 366 R1

BOLT, HEX 5/16NFx1-1/2

SN: P096338-UP

4шт.

4

TRANSMISSION, COMPLETE (SEE FIG. F2320-51A0)

SN: P096338-UP

1шт.

|$18

936 658 C1

RING, SEAL - CASE

SN: P096338-UP

1шт.

|$19

24 889 R1

BOLT, HEX 3/4NCx21/4

SN: P096338-UP

4шт.

|$20

25 538 R1

WASHER, FLAT 3/4

SN: P096338-UP

4шт.

5

621 156 C1

SHIM, MOUNTING 0.002IN

SN: P096338-UP

-2шт.

|$22

621 157 C1

SHIM, MOUNTING 0.007IN

SN: P096338-UP

-2шт.

|$23

621 158 C1

SHIM, MOUNTING 0.020IN

SN: P096338-UP

-2шт.

6

STEERING DRIVE (SEE FIG. F2300-03A1)

SN: P096338-UP

1шт.

7

BRAKE SHOES AND LEVERS(SEE FIG. F2300-02A3)

SN: P096338-UP

1шт.

8

FINAL DRIVE (SEE FIG. F2380-01A0)

SN: P096338-UP

1шт.

|$27

-1шт.

|$28

F1 - WITH TWO PIECE STYLE CONVERTER HOUSING.

-1шт.

|$29

-1шт.

|$30

-1шт.

|$31

F2 - WITH ONE PIECE STYLE CONVERTER HOUSING.

-1шт.

|$32

-1шт.

|$33

-1шт.

|$34

F3 - PART OF TRANSMISSION SERVICE KIT 741 453 C93.

-1шт.

|$35

-1шт.
