Запчасти Komatsu D39E-1A FIG. E-A СИГНАЛ. ЗАДНЕГО ХОДА ЭЛЕКТРИКА

|$0

1315 514 H91

BACK UP ALARM

SN: P096338-UP

1шт.

1

1315 497 H1

ALARM, BACK UP (2 SOUND LEVELS)

SN: P096338-UP

1шт.

|$2

28 161 R1

BOLT, HEX - 3/8NC x 4-1/4

SN: P096338-UP

2шт.

|$3

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

|$4

120 382

WASHER, LOCK - 3/8

SN: P096338-UP

2шт.

2

1122 777 C1

CABLE, ALARM GROUND

SN: P096338-UP

1шт.

3

1278 875 H1

CABLE, POWER (CONNECT TO LO OR HI SOUND LEVEL TERMINAL

-1шт.

4

SWITCH (SEE FIG. E0200-01A0)

SN: P096338-UP

1шт.

5

VALVE, TRANS/STEER (SEE FIG. F2300-09A0)

SN: P096338-UP

1шт.

|$10

-1шт.

|$11

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$12

-1шт.
