Запчасти Komatsu D39E-1A FIG. E-A ЭЛЕКТР. ЭЛЕКТРОПРОВОДКА - КАБИНА ROPS ЭЛЕКТРИКА

1

1270 790 H1

CABLE, STARTER TO BATTERY POS

SN: P096338-UP

1шт.

2

1312 866 H91

HARNESS, MAIN ELECTRICAL

SN: P096338-UP

1шт.

3

1306 802 H91

HARNESS, REAR

SN: P096338-UP

1шт.

4

1236 341 H1

DIODE

SN: P096338-UP

1шт.

5

363 660 R1

CLIP, CLOSED

SN: P096338-UP

1шт.

6

363 660 R1

CLIP, CLOSED

SN: P096338-UP

1шт.

7

299 400 C1

CLIP, CLOSED

SN: P096338-UP

1шт.

8

ALTERNATOR (SEE FIG. A6109-A1A1)

SN: P096338-UP

1шт.

|$8

30 003 R1

BOLT, HEX - M8x25

SN: P096338-UP

1шт.

|$9

120 391

WASHER, FLAT - #10

SN: P096338-UP

2шт.

9

MOTOR, STARTING (SEE FIG. A6112-A1A1)

SN: P096338-UP

1шт.

|$11

31 148 R1

BOLT, HEX - M10x30

SN: P096338-UP

2шт.

|$12

1312 025 H91

SWITCHES, FUSES AND RELAYS

SN: P096338-UP

1шт.

10

621 771 C91

SWITCH, NEUTRAL START

SN: P096338-UP

1шт.

|$14

1232 847 H1

WASHER, NEUTRAL START

SN: P096338-UP

1шт.

|$15

177 717 R1

NUT, HEX - 3/4NF

SN: P096338-UP

1шт.

11

1312 854 H91

RELAY, ASSEMBLY

SN: P096338-UP

2шт.

|$17

22 470 R1

BOLT, HEX - 1/4NCx3/4

SN: P096338-UP

2шт.

|$18

120 392

WASHER, FLAT - 1/4

SN: P096338-UP

2шт.

|$19

120 380

WASHER, LOCK - 1/4

SN: P096338-UP

2шт.

|$20

120 375

NUT, HEX - 1/4NC

SN: P096338-UP

2шт.

|$21

933 833 R1

WASHER, LOCK - M6TERMINAL

SN: P096338-UP

4шт.

|$22

30 281 R1

NUT, HEX - M6TERMINAL

SN: P096338-UP

4шт.

12

1311 302 H1

SWITCH, HOURMETER

SN: P096338-UP

1шт.

|$24

417-01-A1630

SEAL, O-RING

SN: P096338-UP

1шт.

13

740 986 C2

SWITCH, BACK UP

SN: P096338-UP

1шт.

14

1308 132 H1

SWITCH, PLASTIC HOUSING

SN: P096338-UP

1шт.

15

1308 427 H1

PLATE, SWITCH HOUSING

SN: P096338-UP

1шт.

|$28

440 502

SCREW, MOUNTING - #10NCx5/8

SN: P096338-UP

2шт.

|$29

120 391

WASHER, FLAT - #10

SN: P096338-UP

2шт.

16

419-43-12260

SWITCH, GEAR INDICATOR

SN: P096338-UP

3шт.

17

1221 297 H2

SWITCH, TRANS. PRESSURE

SN: P096338-UP

1шт.

18

1209 933 H1

ADAPTOR

SN: P096338-UP

1шт.
