Запчасти Komatsu D39E-1A FIG. C-A ВЕНТИЛЯТОР КОЖУХ И ЧАСТИ КОРПУСА СИСТЕМА ОХЛАЖДЕНИЯ

|$0

1269 788 H91

FAN SHROUDS AND GUARDS

SN: P096338-UP

1шт.

1

1278 564 H1

SHROUD, UPPER FAN

SN: P096338-UP

1шт.

|$2

26 309 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338-UP

4шт.

|$3

25 544 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

2

1278 565 H1

SHROUD, LOWER FAN

SN: P096338-UP

1шт.

|$5

26 309 R1

BOLT, HEX - 3/8NCx3/4

SN: P096338-UP

4шт.

|$6

25 544 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

3

1269 740 H91

GUARD, LEFT FAN

SN: P096338-UP

1шт.

|$8

25 493 R1

BOLT, HEX - 5/16NCx1

SN: P096338-UP

4шт.

|$9

1311 024 H1

WASHER, SPECIAL

SN: P096338-UP

4шт.

4

1269 739 H91

GUARD, RIGHT FAN

SN: P096338-UP

1шт.

|$11

25 493 R1

BOLT, HEX - 5/16NCx1

SN: P096338-UP

5шт.

|$12

1311 024 H1

WASHER, SPECIAL

SN: P096338-UP

5шт.

|$13

25 520 R1

NUT, HEX - 5/16NC

SN: P096338-UP

1шт.

|$14

-1шт.

|$15

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$16

-1шт.
