Запчасти Komatsu D39E-1A FIG. B-A ВПУСК ВОЗДУХА И ВЫПУСКН. СИСТЕМА КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$0

1270 312 H91

AIR INTAKE SYSTEM

SN: P096338-UP

1шт.

1

CLEANER, AIR (SEE FIG. B0300-01A1)

SN: P096338-UP

1шт.

2

1260 202 H1

BAND, MOUNTING

SN: P096338-UP

2шт.

|$3

25 654 R1

BOLT, HEX - 5/16NCx1-1/2

SN: P096338-UP

2шт.

|$4

25 955 R1

BOLT, HEX - 5/16NCx5/8

SN: P096338-UP

4шт.

|$5

25 543 R1

WASHER, FLAT - 5/16

SN: P096338-UP

4шт.

|$6

25 533 R1

WASHER, FLAT - 5/16

SN: P096338-UP

4шт.

|$7

9413 977

NUT, LOCK - 5/16NC

SN: P096338-UP

2шт.

3

1270 833 H92

TUBE, OUTLET

SN: P096338-UP

1шт.

4

1108 177 C2

ELBOW, HOSE

SN: P096338-UP

2шт.

5

613 625 C91

CLAMP, T BOLT

SN: P096338-UP

4шт.

6

1299 271 H1

PIPE, INLET

SN: P096338-UP

1шт.

7

663 432 C1

CLAMP, PIPE

SN: P096338-UP

1шт.

|$13

24 841 R1

BOLT, HEX - 3/8NCx1-1/2

SN: P096338-UP

1шт.

|$14

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

|$15

25 522 R1

NUT, HEX - 3/8NC

SN: P096338-UP

1шт.

8

49 464 DA

CAP, AIR

SN: P096338-UP

1шт.

9

SWITCH, AIR CLEANER VACUUM(SEE FIG. E0200-01A1)

SN: P096338-UP

1шт.

10

INSULATOR, AIR STACK(SEE FIG. M2140-01A0)

SN: P096338-UP

1шт.

|$19

1271 093 H91

EXHAUST SYSTEM

SN: P096338-UP

1шт.

11

1301 659 H1

MUFFLER ASSEMBLY, EXHAUST

SN: P096338-UP

1шт.

|$21

1312 885 H1

CLAMP, MUFFLER

SN: P096338-UP

1шт.

|$22

1287 244 H91

PACKED EXHAUST STACK

SN: P096338-UP

1шт.

12

1286 954 H91

STACK, PACKED EXHAUST

SN: P096338-UP

1шт.

13

674 502 C1

CLAMP, TUBE

SN: P096338-UP

1шт.

|$25

275 804 R1

BOLT, HEX - 3/8NCx3

SN: P096338-UP

1шт.

|$26

25 544 R1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

|$27

25 522 R1

NUT, HEX - 3/8NC

SN: P096338-UP

1шт.

14

HOOD, SOLID (SEE FIG. M2140-02A0)

SN: P096338-UP

1шт.

|$30

OR

-1шт.

|$32

HOOD, PERFORATED (SEE FIG. M2140-02A1)

SN: P096338-UP

1шт.

15

ELBOW, TURBO OUTLET(SEE FIG. B0100-01A0)

SN: P096338-UP

1шт.

|$34

1312 991 H91

FORESTRY EXHAUST STACK

SN: P096338-UP

1шт.

16

1312 948 H91

STACK, FORESTRY EXHAUST

SN: P096338-UP

1шт.

|$36

24 882 R1

BOLT, HEX - 5/8NCX4-1/2

SN: P096338-UP

2шт.

|$37

25 537 R1

WASHER, FLAT - 5/8

SN: P096338-UP

4шт.

|$38

9412 231

NUT, LOCK - 5/8NC

SN: P096338-UP

2шт.

17

1312 951 H1

STACK, EXTENSION

SN: P096338-UP

1шт.

18

674 502 C1

CLAMP, TUBE

SN: P096338-UP

1шт.

|$41

275 804 R1

BOLT, HEX - 3/8NCx3

SN: P096338-UP

1шт.

|$42

25 544 R1

WASHER, FLAT - 3/8

SN: P096338-UP

2шт.

|$43

25 522 R1

NUT, HEX - 3/8NC

SN: P096338-UP

1шт.

|$44

-1шт.

|$45

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$46

-1шт.
