Запчасти Komatsu D39E-1A FIG. B-A КРЕПЛЕНИЕ ДВИГАТЕЛЯ КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$0

1311 113 H91

ENGINE AND MOUNTING

SN: P096338-UP

1шт.

1

1312 818 H91

BRACKET, ENGINE - LEFT - FRONT

SN: P096338-UP

1шт.

|$2

30 043 R1

BOLT, HEX - M12x35

SN: P096338-UP

3шт.

|$3

25 536 R1

WASHER, FLAT - 1/2

SN: P096338-UP

3шт.

2

1312 817 H91

BRACKET, ENGINE - RIGHT - FRONT

SN: P096338-UP

1шт.

|$5

30 043 R1

BOLT, HEX - M12x35

SN: P096338-UP

3шт.

|$6

25 536 R1

WASHER, FLAT - 1/2

SN: P096338-UP

3шт.

3

1312 814 H2

BUSHING, FRONT

SN: P096338-UP

2шт.

|$8

24 881 R1

BOLT, HEX - 5/8NCx4

SN: P096338-UP

2шт.

|$9

25 547 R1

WASHER, FLAT - 5/8

SN: P096338-UP

2шт.

4

1284 656 H1

BUSHING, REAR

SN: P096338-UP

2шт.

5

1299 272 H1

SPACER, BUSHING

SN: P096338-UP

2шт.

6

1312 838 H1

WASHER, BUSHING

SN: P096338-UP

4шт.

|$13

24 881 R1

BOLT, HEX - 5/8NCx4

SN: P096338-UP

2шт.

|$14

25 547 R1

WASHER, FLAT - 5/8

SN: P096338-UP

2шт.

7

1311 384 H1

BRACKET, OIL FILL TUBE SUPPORT

SN: P096338-UP

1шт.

|$16

30 302 R1

BOLT, MOUNTING M10x25

SN: P096338-UP

2шт.

|$17

25 534 R1

WASHER, FLAT -3/8

SN: P096338-UP

2шт.

8

1311 383 H1

TUBE, OIL FILL

SN: P096338-UP

1шт.

9

HOSE -3 IN LONG

SN: P096338-UP

1шт.

10

27 725 R1

CLIP, CLOSED

SN: P096338-UP

3шт.

11

645 272 C1

CLAMP, DIPSTICK

SN: P096338-UP

1шт.

|$22

25 222 R1

BOLT, HEX - 1/4NCx3/4

SN: P096338-UP

1шт.

|$23

25 532 R1

WASHER, FLAT - 1/4

SN: P096338-UP

2шт.

|$24

25 519 R1

NUT, HEX - 1/4NC

SN: P096338-UP

1шт.

12

935 522 C1

TIE, CABLE

SN: P096338-UP

2шт.

13

9410 359

PLUG, HOUSING

SN: P096338-UP

1шт.

14

1281 792 H1

ELBOW, TURBO OUTLET

SN: P096338-UP

1шт.

15

6732-81-8220

CLAMP, V BAND

SN: P096338-UP

1шт.

16

1311 114 H2

BRACKET, TURBO ELBOW

SN: P096338-UP

1шт.

|$30

30 020 R1

BOLT, HEX - M10x25

SN: P096338-UP

4шт.

|$31

25 534 R1

WASHER, FLAT - 3/8

SN: P096338-UP

4шт.

17

ENGINE, S4D102E-1 (SEE FIG. A9101-A1A4)

SN: P096338-UP

1шт.

|$33

-1шт.

|$34

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$35

-1шт.

|$36

-1шт.

|$37

F2 CUT REQUIRED LENGTH FROM BULK HOSE 4011 329 R1.

-1шт.

|$38

-1шт.
