Запчасти Komatsu D39E-1A FIG. B-A OVER ХОД THROTTLE КОМПОНЕНТЫ ДВИГАТЕЛЯ

|$0

1280 359 H91

THROTTLE ASSEMBLY, OVER TRAVEL

SN: P096338-UP

1шт.

1

1258 321 H91

ROD, OVER TRAVEL

SN: P096338-UP

1шт.

2

1258 325 H91

BODY, OVER TRAVEL

SN: P096338-UP

1шт.

3

104 038

CLEVIS, ROD END - 3/8

SN: P096338-UP

1шт.

4

25 523 R1

NUT, HEX - 3/8NF

SN: P096338-UP

1шт.

5

1258 324 H1

BOSS, SPRING STOP

SN: P096338-UP

1шт.

6

20 081 R1

PIN, SPRING - 3/32x3/4

SN: P096338-UP

1шт.

7

1258 326 H1

SPRING, OVER TRAVEL

SN: P096338-UP

1шт.

|$8

-1шт.

|$9

F1 - PART NUMBER IS A NON-SERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$10

-1шт.
