Запчасти Komatsu D39E-1A FIG. T-A РЫХЛИТЕЛЬ SHANK РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

540 976 R93

SHANK ASSEMBLY, RIPPER

SN: P096338-UP

3шт.

1

547 315 R1

POINT, TOOTH

SN: P096338-UP

1шт.

2

492 406 R1

PIN, FLEX

SN: P096338-UP

1шт.

3

NSS

SHANK, RIPPER

SN: P096338-UP

1шт.

|$4

701 494 C91

ADDITIONAL RIPPER TOOTH

SN: P096338-UP

1шт.

|$5

540 976 R93

SHANK ASSEMBLY, RIPPER

SN: P096338-UP

1шт.

1

547 315 R1

POINT, TOOTH

SN: P096338-UP

1шт.

2

492 406 R1

PIN, FLEX

SN: P096338-UP

1шт.

3

NSS

SHANK, RIPPER

SN: P096338-UP

1шт.

4

1303 822 H1

PIN, MOUNTING

SN: P096338-UP

1шт.

|$10

NSS

BOLT, HEX 1/4NCx2

SN: P096338-UP

1шт.

|$11

NSS

NUT, LOCK 1/4NC

SN: P096338-UP

1шт.

|$12

-1шт.

|$13

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$14

-1шт.
