Запчасти Komatsu D39E-1A FIG. T-A РЫХЛИТЕЛЬ РАБОЧЕЕ ОБОРУДОВАНИЕ

|$0

1281 349 H91

RIPPERFACTORY

SN: P096338-UP

1шт.

|$1

1301 292 H91

RIPPERFIELD

SN: P096338-UP

1шт.

|$2

701 488 C91

FRAME AND STABILIZER

SN: P096338-UP

1шт.

1

541 027 R1

TOOLBEAM

SN: P096338-UP

1шт.

2

LINK, UPPER (SEE FIG. T2410-01A1)

SN: P096338-UP

1шт.

3

LINK, LOWER (SEE FIG. T2410-01A1)

SN: P096338-UP

1шт.

4

540 994 R91

PIN, LINK

SN: P096338-UP

4шт.

|$7

271 547

BOLT, HEX - 5/8NCx1-1/2

SN: P096338-UP

2шт.

|$8

23 276 R1

WASHER, FLAT - 5/8

SN: P096338-UP

2шт.

|$9

121 574

WASHER, LOCK - 5/8

SN: P096338-UP

2шт.

|$10

492 389 R1

KEEPER, BOLT

SN: P096338-UP

2шт.

|$11

109 461

FITTING, LUBE

SN: P096338-UP

4шт.

5

540 998 R1

PIN, REAR UPPER LINK

SN: P096338-UP

2шт.

|$13

271 547

BOLT, HEX - 5/8NCx1-1/2

SN: P096338-UP

2шт.

|$14

23 276 R1

WASHER, FLAT - 5/8

SN: P096338-UP

2шт.

|$15

121 574

WASHER, LOCK - 5/8

SN: P096338-UP

2шт.

|$16

492 389 R1

KEEPER, BOLT

SN: P096338-UP

2шт.

|$17

109 461

FITTING, LUBE

SN: P096338-UP

2шт.

6

541 001 R1

PIN, REAR LOWER LINK

SN: P096338-UP

2шт.

|$19

109 461

FITTING, LUBE

SN: P096338-UP

2шт.

7

541 003 R1

RING, CORD

SN: P096338-UP

16шт.

|$21

701 489 C91

CYLINDERS

SN: P096338-UP

1шт.

8

CYLINDER, RIPPER (SEE FIG. T2450-01A0)

SN: P096338-UP

2шт.

|$23

109 461

FITTING, LUBE

SN: P096338-UP

4шт.

9

541 004 R1

PIN, CYLINDER

SN: P096338-UP

2шт.

|$25

24 863 R1

BOLT, HEX - 1/2NCx1-3/4

SN: P096338-UP

2шт.

|$26

120 384

WASHER, LOCK - 1/2

SN: P096338-UP

2шт.

|$27

21 330 R1

NUT, HEX - 1/2NC

SN: P096338-UP

2шт.

10

851 506 C1

PIN, CYLINDER

SN: P096338-UP

2шт.

|$29

378 484 R1

PIN, HEADED - 5/16x2

SN: P096338-UP

2шт.

|$30

12 235 R1

PIN, COTTER - 1/8x5/8..

SN: P096338-UP

2шт.

|$31

701 491 C91

TOOTH AND PINS

SN: P096338-UP

1шт.

11

TOOTH, RIPPER (SEE FIG. T2430-01A0)

SN: P096338-UP

3шт.

12

392 158 R1

PIN, INNER TOOTH

SN: P096338-UP

1шт.

|$34

180 044

BOLT, HEX - 1/4NCx1-3/8

SN: P096338-UP

1шт.

|$35

23 911 R1

NUT, LOCK - 1/4NC

SN: P096338-UP

3шт.

13

1303 822 H1

PIN, OUTER TOOTH

SN: P096338-UP

2шт.

|$37

180 044

BOLT, HEX - 1/4NCx1-3/8

SN: P096338-UP

2шт.

|$38

23 911 R1

NUT, LOCK - 1/4NC

SN: P096338-UP

3шт.

|$39

1281 355 H91

FRAME AND MOUNTING

SN: P096338-UP

1шт.

14

1280 899 H91

FRAME, MOUNTING

SN: P096338-UP

1шт.

|$41

24 890 R1

BOLT, HEX - 3/4NCx2-1/2

SN: P096338-UP

8шт.

|$42

25 848 R1

BOLT, HEX - 1-1/8NCx3

SN: P096338-UP

4шт.

15

TOOTH, ADDITIONAL(SEE FIG. T2430-01A0)

SN: P096338-UP

1шт.

|$44

-1шт.

|$45

F1 PART NUMBER IS A NONSERVICE PART AND IS LISTED FOR REFERENCE ONLY. ORDER INDIVIDUAL PIECE PARTS.

-1шт.

|$46

-1шт.
